Schneider Electric 140DDM39000 Mixed Discrete I/O Module

Schneider Electric 140DDM39000 Mixed Discrete I/O Module

Product Name: Mixed Discrete I/O Module

Brand Name: Schneider Electric

Model Number: 140DDM39000

Place of Origin: France

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Specifications
Commercial Terms
Description
Features
FAQ
After-sales Service
Major Business
Recommended Products

Contact Info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Schneider Electric 140DDM39000 Mixed Discrete I/O Module
Manufacturer	Schneider Electric
Product Type	Mixed Discrete I/O Module
Part Number	140DDM39000
Place of shipment	Xiamen, China
Country of origin	France
Total Discrete I/O	24
Discrete Inputs	16 inputs, 2 groups of 8
Input Logic	Sink
Input Voltage	24 V DC
Input State 0	-3 to +5 V; ≤ 0.5 mA
Input State 1	15 to 30 V; ≥ 2 mA
Input Impedance	2,500 Ω
Discrete Outputs	8 outputs, 2 groups of 4
Output Type	Solid State
Output Logic	Sink
Output Voltage	24 V DC
Output Voltage Range	19.2–30 V DC typical
Maximum Load Current	≤ 0.5 A per point; ≤ 2 A per group; ≤ 4 A per module
Voltage Drop	0.4 V at 0.5 A
Absolute Maximum Output	5 A for 500 µs per point
Load Inductance	500 mH at 4 Hz
Load Capacitance	≤ 50 µF
Leakage Current	0.4 mA at 30 V DC
Output Response Time	≤ 1 ms, OFF→ON; ≤ 1 ms, ON→OFF
Output Protection	Internal protection with 5 A fuse per group; transient voltage suppression
Associated Fuse Rating	5 A per group
Isolation Between Groups	500 Vrms for 1 minute
Isolation Between Group and Bus	1,780 Vrms for 1 minute
Bus Current Requirement	330 mA
Marking	CE
Operating Temperature	0 to 60 °C
Storage Temperature	-40 to +85 °C
Relative Humidity	95% without condensation
Operating Altitude	≤ 5,000 m
Standards	CSA C22.2 No. 142; FM Class 1 Division 2; UL 508
Certification	CUL

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Schneider Electric 140DDM39000 is a mixed discrete I/O module designed for the Modicon Quantum automation platform, combining 16 sink-type 24 VDC digital inputs and 8 sink-type solid-state 24 VDC outputs in a single module. Its outputs support loads up to 0.5 A per point and provide fast switching response of 1 ms or less, while group-level fusing, transient voltage suppression, and electrical isolation help protect the I/O system. By integrating both input monitoring and output control functions into one module, it can reduce rack space and simplify field wiring. It is well suited for machine automation, production lines, material handling, process equipment, and other Quantum-based systems requiring centralized discrete signal acquisition and control.

Features

Combines 16 digital inputs and 8 digital outputs in one module.
Provides a total of 24 discrete I/O points.
Designed for Modicon Quantum automation systems.
Digital inputs are arranged in two groups of 8.
Uses sink logic for the digital input channels.
Input channels operate with 24 VDC field signals.
Digital outputs are arranged in two groups of 4.
Uses solid-state sink-type output switching.
Output operating range is typically 19.2–30 VDC.
Supports output loads up to 0.5 A per point.
Supports up to 2 A total output current per group.
Supports up to 4 A total output current per module.
Output ON and OFF response times are 1 ms or less.
Internal output protection helps protect against abnormal load conditions.
Each output group is protected by a 5 A fuse.
Includes transient voltage suppression for output protection.
Provides electrical isolation between I/O groups.
Provides isolation between field-side groups and the system bus.
CE marked and cUL certified.
Meets applicable UL 508, CSA C22.2 No. 142, and FM Class I Division 2 requirements.

FAQ

1. What is the Schneider Electric 140DDM39000 used for?
The Schneider Electric 140DDM39000 is used to monitor 24 VDC discrete field signals and control compatible DC loads within Modicon Quantum industrial automation systems.

2. How many I/O points does the Schneider Electric 140DDM39000 provide?
The Schneider Electric 140DDM39000 provides 24 discrete I/O points, consisting of 16 inputs and 8 outputs.

3. What type of inputs does the Schneider Electric 140DDM39000 have?
The Schneider Electric 140DDM39000 provides 16 sink-type 24 VDC digital inputs arranged in two groups of eight.

4. What type of outputs does the Schneider Electric 140DDM39000 provide?
The Schneider Electric 140DDM39000 provides eight solid-state, sink-type 24 VDC outputs arranged in two groups of four.

5. What is the maximum output current of the Schneider Electric 140DDM39000?
The Schneider Electric 140DDM39000 supports up to 0.5 A per output point, 2 A per group, and 4 A for the complete module.

6. How fast are the outputs of the Schneider Electric 140DDM39000?
The Schneider Electric 140DDM39000 has specified OFF-to-ON and ON-to-OFF response times of 1 ms or less.
