Product Name: PanelView Plus 600 Grayscale Operator Interface Module
Brand Name: Allen-Bradley
Model Number: 2711P-B6M20D
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Allen-Bradley 2711P-B6M20D PanelView Plus 600 Grayscale Operator Interface Module |
| Manufacturer | Allen-Bradley |
| Product Type | PanelView Plus 600 Grayscale Operator Interface Module |
| Part Number | 2711P-B6M20D |
| Weight | 0.88kg |
| Estimated shipping dimensions | 26.5x10.5x16.6cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Operator Input | Keypad/Touch combination |
| Communication Interface | Ethernet, RS-232, and Modular Communication Interface |
| Power Supply | DC power |
| Display Technology | Monochrome Passive Matrix, Film Compensated Super-Twist Nematic (FSTN) |
| Display Size | 111 × 84 mm (5.5 in.) |
| Display Resolution | 320 × 240, 32-level grayscale |
| Panel Cutout Dimensions (H × W) | 142 × 241 mm |
| Power Requirements | 18-32V DC |
| Replaceable Backlight | No |
| Function Keys | 10 function keys, F1–F10 |
| Real-Time Clock | Battery-backed; accuracy of ±2 minutes per month |
| Flash / RAM | Standard 32 MB / 64 MB; not expandable |
| Communication Ports | Ethernet, RS-232, and one USB port; optional DH-485, DH+, or Remote I/O communication modules |
| Power Consumption | 25 Watts max. (1.0A @ 24V DC) |
| Programming Software | RSView Studio for Machine Edition or Enterprise Series |
| Operating Temperature | 0–55°C |
| Storage Temperature | −25–70°C |
| Humidity | 5–95%, noncondensing at 0–55°C |
| Enclosure Ratings | NEMA 12, 13, and 4X; IP54 and IP65 |
| Certifications | cUL certified; UL listed; Class 1, Division 2, Groups A, B, C, and D; Class 2, Division 2, Groups F and G; Class 3, Division 1; CE marked; C-Tick |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Allen-Bradley 2711P-B6M20D is a PanelView Plus 600 Grayscale Operator Interface Module designed for industrial HMI, machine control, and process monitoring applications. It combines keypad and touchscreen operation with Ethernet and RS-232 connectivity, providing flexible communication with compatible Allen-Bradley PLC and automation systems. The 2711P-B6M20D is well suited for manufacturing machinery, production lines, process control, factory automation, and maintenance or replacement of existing PanelView Plus 600 HMI systems.
