Product Name: PanelView Plus 400 Operator Interface Module
Brand Name: Allen-Bradley
Model Number: 2711P-K4M20D
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Allen-Bradley 2711P-K4M20D PanelView Plus 400 Operator Interface Module |
| Manufacturer | Allen-Bradley |
| Product Type | PanelView Plus 400 Operator Interface Module |
| Part Number | 2711P-K4M20D |
| Weight | 0.54kg |
| Estimated shipping dimensions | 18.5x9.6x15.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Operator Input | Keypad |
| Interface | Ethernet, RS-232, and modular communication interface |
| Power Supply | DC power |
| Display Technology | Monochrome Passive Matrix, Film Compensated Super-Twist Nematic (FSTN) |
| Display Size | 78 × 59 mm (3.7 in.) |
| Panel Cutout Dimensions | 123 × 156 mm |
| Display Resolution | 320 × 240, 32-level grayscale |
| Power Requirements | 18-32V DC |
| Maximum Power Consumption | 25 Watts max. (1.0A @ 24V DC) |
| Replaceable Backlight | No |
| Function Keys | 8 function keys, F1-F8 |
| Real-Time Clock | Battery-backed; accuracy of ±2 minutes per month |
| Flash / RAM | Standard 32 MB / 64 MB; not expandable |
| Communication Ports | Ethernet, RS-232, one USB port, and modular communication interface |
| Programming Software | RSView Studio for Machine Edition or Enterprise Series |
| Operating Temperature | 0-55°C |
| Storage Temperature | -25-70°C |
| Humidity | 5-95%, noncondensing at 0-55°C |
| Enclosure Ratings | NEMA 12, 13, and 4X; IP54 and IP65 |
| Certifications | cUL certified; UL listed; Class 1, Div 2, Groups A, B, C, and D; Class 2, Div 2, Groups F and G; Class 3, Div 1; CE marked; C-Tick |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Allen-Bradley 2711P-K4M20D is a PanelView Plus 400 Operator Interface Module designed for industrial HMI, machine control, and process monitoring applications. It features keypad operation, a monochrome display, and Ethernet and RS-232 communication for integration with compatible Allen-Bradley PLC and automation systems. The 2711P-K4M20D provides a compact operator interface for manufacturing machinery, production equipment, process control, factory automation, and maintenance or replacement of existing PanelView Plus HMI systems.
