Nomen producti: SIMATIC DP ET 200PRO High Feature Electronic Module
Nomen marcae: Siemens
Numerus exemplaris: 6ES7144-4PF00-0AB0
Locus originis: Germania
Warranty: 12 menses
Whatsapp:+86 18020776782
Epistula electronica： [email protected]
Minimum quantitas ordinis |
1 piece |
Pretium |
Contactus pro Jim |
Singula Packaging |
Originales nova Officina Sigillata |
Tempus Traditionis |
3–7 dies |
Condiciones solutionis |
T/T |
Shipping modum |
DHL / FedEx / UPS / TNT |
Capacitas Supplicandi |
In stirpe |
| Nomen Producti | Siemens 6ES7144-4PF00-0AB0 SIMATIC DP ET 200PRO High Feature Electronic Module |
| Fabricator | Siemens |
| Product Type | SIMATIC DP ET 200PRO High Feature Electronic Module |
| Numerus partis | 6ES7144-4PF00-0AB0 |
| Locus navandi | Xiamen, Sinae |
| Patria Origin | Germania |
| Numerus Ingressuum Analogicorum | 4 |
| Tipus de termopare suportats | B, E, J, K, L, N, R, S, T |
| Intervallum Input Voltus | −80 mV ad +80 mV |
| Tensio nominalis supplicii | 24 V DC |
| Protectio ab polaritate inversa | Sic, contra destructionem |
| Consum de corrent des de 1L+ | Típicament 34 mA |
| Cūrrens dorsi bus | Típicament 20 mA a 3,3 V CC |
| Perditio potentiæ typica | 0,7 W |
| Maxima Spatium Adressarum | 8 Octetta |
| Maxima Tensio Ingressus Permissa | 20 V (límit de destrucció) |
| Resistentia input | 10 MΩ (-80 mV a +80 mV) |
| Maxima Longitudo Cavi Scutati | 30 m |
| Principium mensurationis | Integrating |
| Maxima Resolutio | 15 bit + signum, includens superlimitationem |
| Tempus Integrationis | 2.5 / 16.67 / 20 / 100 ms |
| Suppressio Frequentiae Interferentis | 10 / 50 / 60 / 400 Hz |
| Tempus Conversionis per Canal | 4.7 / 19 / 22 / 102 ms |
| Levigationem valoris mensurati | Yes, Parameterizable |
| Mensura voltii | Ita |
| Error Linearitatis | ±0.01% intervali introducti |
| Error Temperaturae | ±0.0004%/K (temperatura positiva) |
| Crosstalk entre entradas | -90 dB |
| Accuratio Repetitionis ad 25°C | ±0.01% intervali introducti |
| Limitis Erroris Operationalis | ±0.12% intervali intrantis (tensio, temperatura positiva) |
| Limitis Erroris Fundamentalis ad 25°C | ±0.1% of input range |
| Series-Mode Interference Rejection | ≥42 dB |
| Common-Mode Interference Rejection | ≥85 dB (USS < 2.5 V; interference voltage < 10 V) |
| Functio Diagnostica | Ita |
| Tensio Probae Isolationis | 707 V DC (Examen Typi) |
|
Sales |
Electronicum |
Telephus WhatsApp |
|
Iimus Pei |
The Siemens 6ES7144-4PF00-0AB0 SIMATIC DP ET 200PRO High Feature Electronic Module is a high-precision 4-channel analog input module designed for temperature and low-level voltage measurement within the SIMATIC ET 200PRO distributed I/O system. It supports a wide range of thermocouple types including B, E, J, K, L, N, R, S, and T, as well as voltage signals from -80 mV to +80 mV. With 15-bit + sign resolution, integrating measurement technology, parameterizable smoothing, selectable interference suppression, and integrated diagnostics, the module provides accurate and stable acquisition of temperature and millivolt signals. Its high input impedance, excellent interference rejection, and 707 VDC isolation testing make it suitable for demanding industrial measurement and process monitoring applications.
The Siemens 6ES7144-4PF00-0AB0 est designatus ad exactam acquisitionem temperaturae et signorum millivoltorum e thermocupulis et sensoribus tensionis inferioris compatibilibus. Id est praesertim idoneum ad applicationes ut fornaces industriales et fornaces, apparatus ad tractationem caloris, machinas ad elaborationem plasticorum, lineas productionis temperaturae regulatae, processus chemicos, apparatus experimentales, et alia systemata ubi monitoratio temperaturae multicanalis accurata requiritur.
Ut pars platformae SIMATIC ET 200PRO, modulus etiam bene aptus est ad applicationes distributionis mensurae et controlis in fabrica automobilium, in elaboratione cibi et potus, in machinis ad impachetandum, in elaboratione metallorum, in systematibus energiae, et in automatione generali fabricae. Amplam compatibilitatem cum thermocupulis, filtrum configurabilem, altam accuratitudinem mensurae, et facultates diagnosticas habet, quae permittunt monitoriam temperaturae fidelem prope processum productionis, simul integrationem in systemata automationis Siemens simplificant.
