Product Name: ArmorPOINT I/O Digital Input Module
Brand Name: AB
Model Number: 1738-IB16DM12
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Machine Automation Module | 16-Point Digital Input Module |
| Industrial Control Module | Allen-Bradley I/O Module |
| Allen-Bradley Spare Parts | POINT I/O Module |
| ArmorPOINT Digital Input | Industrial Automation I/O |
| Factory Automation I/O Module | PLC Input Module |
| Industrial Field I/O Module | Distributed I/O Module |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The Allen-Bradley 1738-IB16DM12 ArmorPOINT I/O Digital Input Module is a rugged 16-point digital input module designed for distributed industrial automation systems. Operating on 24 VDC, it provides reliable signal acquisition from field devices while supporting ArmorPOINT I/O architectures. Its compact, durable design ensures dependable performance in demanding factory automation and machine control applications.
| Product Name | AB 1738-IB16DM12 ArmorPOINT I/O Digital Input Module |
| Manufacturer | Allen-Bradley |
| Product Type | ArmorPOINT I/O Digital Input Module |
| Part Number | 1738-IB16DM12 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 7x5.5x11.1cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Number of Input Points | 16 points |
| Rated Input Voltage | 24 V DC |
| Input Voltage Range (ON) | 10 V DC (min) ~ 28.8 V DC (max) |
| Input Current (ON) | 2 mA (min), 4 mA (typical @ 24 V DC), 5 mA (max) |
| OFF Status Voltage | ≤5 V DC |
| OFF Status Current | ≤1.5 mA |
| Sensor Power Supply Current per Point | Max 50 mA |
| Total Sensor Power Supply Current per Module | Max 800 mA |
| Field Power Supply Voltage Range | 10～28.8 V DC |
16 High-Density Input Channels
Provides efficient digital signal acquisition in a compact module.
Reliable 24 VDC Operation
Designed for standard industrial control systems.
Integrated Sensor Power
Supplies up to 800 mA total sensor power for connected devices.
Fast Signal Response
Ensures accurate monitoring of digital field inputs.
Compact ArmorPOINT Design
Saves installation space while simplifying system expansion.
Easy Integration
Compatible with Allen-Bradley ArmorPOINT distributed I/O systems.
Industrial Durability
Designed for reliable performance in harsh manufacturing environments.
Reduced Wiring Costs
Distributed I/O architecture minimizes cabinet wiring complexity.
Q1: What is 1738-IB16DM12 used for?
A: 1738-IB16DM12 is a 16-point digital input module used to collect digital signals from sensors, switches, and field devices in Allen-Bradley ArmorPOINT I/O systems.
Q2: How many input channels does 1738-IB16DM12 provide?
A: 1738-IB16DM12 provides 16 digital input channels for reliable field signal monitoring.
Q3: What input voltage does 1738-IB16DM12 support?
A: 1738-IB16DM12 operates with a rated input voltage of 24 VDC and supports an input voltage range of 10 VDC to 28.8 VDC.
Q4: Does 1738-IB16DM12 provide sensor power?
A: 1738-IB16DM12 provides up to 50 mA of sensor power per input point, with a maximum total sensor supply current of 800 mA per module.
Q5: Which systems are compatible with 1738-IB16DM12?
A: 1738-IB16DM12 is designed for Allen-Bradley ArmorPOINT distributed I/O systems used in PLC-based industrial automation applications.
