Product Name: Process Panel In stock
Brand Name: ABB
Model Number:PP235 3BSC690102R2
Country of Origin:SWEDEN
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
PP235 3BSC690102R2 |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Manufacturer |
ABB |
|
Model Number |
PP235 |
|
Order Number |
3BSC690102R2 |
|
Catalog Description |
PP235 Process Panel 235 |
|
Product Type |
Control System Accessory / Operator Panel |
|
Display Type |
5.7-inch Function Key Panel |
|
Series Family |
ABB Panel 800 |
|
System Compatibility |
ABB Advant 800xA, Panel 800 series |
|
Regulatory Compliance |
|
|
WEEE Category |
|
|
Customs Tariff Number |
84714100 |
|
Dimensions |
27.5x19.3x9.5cm |
|
Product Net Weight |
|
|
Operating Conditions |
For indoor industrial use only |
|
Mounting Type |
Panel mount (typical for Panel 800 series) |
|
Spare Part Classification |
|
|
Upgrade Replacement |
PP836A (3BSE042237R2) – when full RoHS compliance or larger display is required |
The ABB PP235 3BSC690102R2 is a spare part operator panel belonging to ABB‘s Panel 800 family, designed with a 5.7” function key interface for industrial human-machine interaction. The PP235 3BSC690102R2 is a legacy spare part intended for ABB Advant 800xA automation systems placed on the market before July 22, 2017, and is authorized exclusively for repair, reuse, functionality updates, or capacity upgrades in existing installations.
As a member of the Panel 800 series, the ABB PP235 serves as a user-friendly and ergonomic operator panel that combines space-saving dimensions with practical control functions accessible via dedicated function keys. The PP235 3BSC690102R2 is specifically designed to interface with System 800xA and other ABB control platforms, enabling operators to monitor and control distributed control processes efficiently. According to ABB‘s official documentation, the intended upgrade path for the ABB PP235 3BSC690102R2 is the PP836A (3BSE042237R2), which features a slightly larger display area.
It is critical to note that the PP235 3BSC690102R2 is NOT RoHS 2 (2011/65/EU) compliant, a factor that restricts its use to legacy system maintenance applications where the original equipment was placed into service before July 2017. For full-replacement modernization projects, ABB recommends transitioning to newer-generation Panel 800 units with full RoHS compliance and contemporary HMI features.
Energy and Power Generation – Legacy thermal, nuclear, and alternative energy plant HMI legacy interfaces.
Oil, Gas, and Petrochemicals – Monitoring installations placed into service before 2017 that retain 800xA communication.
Metals, Mining, and Cement – Factory-floor legacy monitoring where function-key operation is preferred.
Water and Wastewater Treatment – Rehabilitation of older plant automation cabinets without full control system replacement.
800xA System Maintenance – Direct integration with existing Advant 800xA infrastructure for repair or capacity expansion.
Compact, Space-Saving Form Factor – Panel 800 design philosophy emphasizing slim dimensions without excessive weight (2 grams net).
Ergonomic Industrial Design – User-friendly human-machine interface layout supporting intuitive operation and quick response to alarms or commands.
Legacy System Compatibility – Matched explicitly to pre-July 2017 Advant 800xA installations; preserves infrastructure investment.
Intended Spare Part Classification – Specifically authorized for repair, reuse, upgrade, or capacity expansion of older ABB systems.
Durable Industrial Construction – Robust build quality suitable for demanding manufacturing and process environments.
Clear Upgrade Path – Officially replaceable by PP836A (3BSE042237R2) for projects requiring full RoHS compliance or larger screen real estate.
Human-Machine Process Interface – Displays real-time process variables, alarms, and system feedback through the 5.7-inch function key display.
Operator Command Execution – Dedicated function keys trigger start, stop, reset, emergency stop, and other equipment control tasks without requiring touchscreen navigation.
800xA System Integration – Connects with ABB Advant 800xA DCS platforms to facilitate monitoring, configuration, and interaction with distributed control processes.
Alarm and Event Indication – Visual notification of process alarms, sensor faults, and equipment status for rapid operator response.
Control Function Allocation – Function keys can be programmed/configured to execute specific automation tasks such as mode switching, setpoint changes, or manual overrides.
Legacy System Extension – Serves as a capacity upgrade or functionality update component when adding new operator stations to an existing 800xA network.
Q1: Is the ABB PP235 3BSC690102R2 compatible with modern 800xA systems?
A: The ABB PP235 3BSC690102R2 is intended specifically for legacy Advant 800xA systems placed on the market before July 22, 2017. While it may interface with older versions, full compatibility with current-generation 800xA System software cannot be guaranteed without thorough testing. For new 800xA installations, ABB recommends using the PP836A (3BSE042237R2) or other contemporary Panel 800 units.
Q2: Why is the PP235 3BSC690102R2 not RoHS compliant?
A: The PP235 3BSC690102R2 predates the strict enforcement of RoHS 2 (Directive 2011/65/EU). This device is a spare part explicitly authorized by ABB for use only in systems originally placed into service before July 22, 2017, and may not be sold or installed as a new component in modern RoHS-compliant control cabinets.
Q3: What is the replacement or upgrade option for the ABB PP235?
A: ABB clearly states that the intended upgrade unit for the PP235 3BSC690102R2 within the Panel 800 family is the PP836A (3BSE042237R2). The newer panel offers a slightly larger display area and complies with current RoHS environmental standards. For any application not restricted to legacy spares, migrating to the PP836A is strongly advised.
Q4: Can the PP235 3BSC690102R2 be used with systems other than ABB 800xA?
A: While the ABB PP235 is primarily designed and validated for the Advant 800xA ecosystem, the open architecture of the Panel 800 series may allow limited compatibility with certain ABB control platforms sharing common communication standards. However, ABB does not guarantee full function or reliable operation outside its specified 800xA environment.
Q5: What is the net weight of the ABB PP235 3BSC690102R2?
A: The product net weight of the PP235 3BSC690102R2 is recorded as 0.002 kg (approximately 2 grams) in ABB‘s official documentation. This extremely low weight reflects that the listed value likely represents the electronic module alone. Field-installed units require suitable panel-mount hardware, which contributes additional mass beyond the stated module weight.
