Product Name: PC Pulse Counting Board
Brand Name: ABB
Model Number: DSDP170 57160001-ADF
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB DSDP170 57160001-ADF PC Pulse Counting Board is a high-speed industrial pulse processing module designed for accurate signal counting and measurement in automation systems. It is used to process fast pulse signals from devices such as encoders, sensors, and measurement instruments in applications including speed monitoring, position tracking, and flow control. With a maximum pulse frequency of 2.5 MHz, 500 VAC channel-to-channel isolation, and low-power 24 V DC operation, it provides stable and precise performance in demanding industrial environments.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB DSDP170 57160001-ADF PC Pulse Counting Board |
| Manufacturer | ABB |
| Product Type | PC Pulse Counting Board |
| Part Number | DSDP170 57160001-ADF |
| Weight | 0.32kg |
| Estimated shipping dimensions | 2x24.8x24.4cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Power Supply | 24 VDC |
| Consumption | ≤ 50 mA @ 24 V |
| Input Current | ≤ 10 mA |
| Maximum Pulse Frequency | 2.5 MHz |
| Isolation | 500 VAC channel-to-channel |
| Operating Temp. | –20 °C to +60 °C |
Ultra-High-Speed Performance
The DSDP170 supports up to 2.5 MHz pulse frequency, enabling significantly faster signal processing than standard pulse counting boards.
Strong Channel Isolation
With 500 VAC channel-to-channel isolation, it enhances system safety and reduces electrical interference between input channels.
Low Power Consumption
Operating at ≤ 50 mA, it offers energy-efficient performance suitable for continuous industrial use.
High Measurement Accuracy
Designed for precise detection of fast and narrow pulses, ensuring reliable data in critical control applications.
Stable Industrial Reliability
Built for ABB automation systems, it ensures consistent long-term performance in industrial environments.
The ABB DSDP170 57160001-ADF PC Pulse Counting Board is designed for installation in industrial control cabinets and operates on a 24 V DC power supply. It functions reliably within an operating temperature range of –20 °C to +60 °C. The module is intended for use in standard industrial environments where electromagnetic interference, vibration, and electrical noise are controlled. Proper installation in a ventilated and protected enclosure is recommended to ensure stable high-speed pulse processing and long-term operational reliability.
Q1: What is ABB DSDP170 57160001-ADF used for?
The ABB DSDP170 57160001-ADF is used for high-speed pulse counting and signal processing in industrial automation systems.
Q2: What is the maximum pulse frequency of ABB DSDP170 57160001-ADF?
The ABB DSDP170 57160001-ADF supports a maximum pulse frequency of 2.5 MHz.
Q3: What type of electrical isolation does ABB DSDP170 57160001-ADF provide?
The ABB DSDP170 57160001-ADF provides 500 VAC channel-to-channel isolation for improved safety and signal stability.
Q4: What is the power supply requirement for ABB DSDP170 57160001-ADF?
The ABB DSDP170 57160001-ADF operates on a 24 V DC power supply.
Q5: What is the operating temperature range of ABB DSDP170 57160001-ADF?
The ABB DSDP170 57160001-ADF operates between –20 °C and +60 °C.
Q6: Why is ABB DSDP170 57160001-ADF used in industrial systems?
The ABB DSDP170 57160001-ADF is widely used due to its ultra-high-speed pulse counting capability, strong isolation, low power consumption, and reliable industrial performance.
