Product Name: Power Supply Module
Brand Name: ABB
Model Number: DSQC604 3HAC12928-1
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Robotics Power Module | IRC5 Power Supply |
| ABB Automation Components | ABB IRC5 Spare Parts |
| ABB Robot Spare Parts | ABB Robot Power Module |
| IRC5 Controller Module | Industrial Power Supply |
| Industrial Automation Power Supply | 24V DC Power Supply |
| ABB Replacement Power Supply | ABB Controller Power Supply |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The ABB DSQC604 3HAC12928-1 Power Supply Module is a high-efficiency power supply designed for ABB IRC5 robotic controller systems. It converts 230V AC input into four isolated 24V DC output channels, providing reliable power distribution and advanced protection for critical controller components. Its drop-in replacement design ensures easy installation and dependable operation in industrial automation environments.
| Product Name | ABB DSQC604 3HAC12928-1 Power Supply Module |
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Part Number | DSQC604 3HAC12928-1 |
| Weight | 2.32 kg |
| Estimated shipping dimensions | 8x15.6x20cm |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Input Voltage | 230 V AC, 50/60 Hz |
| Input Current (Max) | 6 A |
| Output Channels | 4 (PC, SYS, COOL, CHARGE) |
| PC Output | 24 V DC, 5 A (Main computer & I/O) |
| SYS Output | 24 V DC, 5 A (Servo drive interface) |
| COOL Output | 24 V DC, 1 A (Internal cooling fans) |
| CHARGE Output | 24 V DC, 0.6 A (Backup battery) |
| Efficiency (Typical) | ≥ 90% |
| Protection | Overvoltage, overcurrent, short-circuit, overtemperature |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +85°C |
Four Independent Output Channels
Supplies dedicated power to critical controller subsystems for greater reliability.
Intelligent Fault Protection
Isolates only the affected channel while keeping essential systems operational.
High Energy Efficiency
Delivers typical efficiency of 90% or higher, reducing energy consumption.
Easy Drop-in Replacement
Directly compatible with ABB IRC5 single-cabinet systems without wiring modifications.
Comprehensive Protection
Includes overvoltage, overcurrent, short-circuit, and overtemperature protection.
Reliable Continuous Operation
Designed for demanding 24/7 industrial automation applications.
Quick Installation
Features plug-and-play connectors for reduced maintenance time.
Long Service Life
Engineered for dependable long-term operation in robotic manufacturing environments.
Q1: How many output channels does ABB DSQC604 3HAC12928-1 provide?
A: DSQC604 3HAC12928-1 provides four independent 24V DC output channels for PC, SYS, COOL, and CHARGE functions.
Q2: What protection features are included in ABB DSQC604 3HAC12928-1?
A: DSQC604 3HAC12928-1 includes protection against overvoltage, overcurrent, short circuits, and overheating, while independently protecting each output channel.
Q3: Is ABB DSQC604 3HAC12928-1 compatible with ABB IRC5 controllers?
A: DSQC604 3HAC12928-1 is specifically designed as a direct replacement for ABB IRC5 single-cabinet controller systems, requiring no wiring modifications.
Q4: How does ABB DSQC604 3HAC12928-1 improve system reliability?
A: DSQC604 3HAC12928-1 uses galvanically isolated outputs and intelligent fault management to prevent failures on one channel from affecting the entire control system.
Q5: Is ABB DSQC604 3HAC12928-1 suitable for continuous industrial operation?
A: DSQC604 3HAC12928-1 is engineered for continuous industrial use, offering high efficiency, stable performance, and reliable operation in demanding manufacturing environments.
