ABB PHARPS32200000 Power Supply Module

Product Name: Power Supply Module

Brand Name: ABB

Model Number: PHARPS32200000

Place of Origin: SWEDEN

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb pharps32200000 power supply module-1

Overview
Contact Info
Parameter
Introduction
Function
Features
Applications & Use Cases
System Compatibility
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter

Product Name	ABB PHARPS32200000 Power Supply Module
Manufacturer	ABB
Product Type	Power Supply Module
Part Number	PHARPS32200000
Weight	5.1kg
Estimated shipping dimensions	8.9x44.5x21.5cm
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Input Voltage	24 V DC
Output Voltage	5 V DC
Output Current	6 A (30 W) continuous
Holdup Time	> 20 ms at full load
Efficiency	> 85%
Ripple & Noise	< 100 mV peak-to-peak
Operating Temperature	-25°C to +70°C
Storage Temperature	-40°C to +85°C
Humidity	5 - 95% RH (non-condensing)

Introduction

The ABB PHARPS32200000 Power Supply Module is a high-reliability industrial power supply unit designed to provide stable and regulated power for ABB automation and control systems. It converts a 24 V DC input into a precisely controlled 5 V DC output, supplying the essential operating power required by control processors, I/O modules, and communication components. With a continuous output current of 6 A (30 W), the module is engineered to support critical system operation in demanding industrial environments.

Manufactured by ABB in Sweden, the PHARPS32200000 is built for robust performance, long service life, and high electrical stability. Its efficient design, with greater than 85% efficiency and low ripple/noise characteristics (<100 mV peak-to-peak), ensures clean and reliable power delivery. With extended operating temperature tolerance and strong environmental resistance, it is suitable for continuous use in process industries, power plants, and factory automation systems.

Function

The PHARPS32200000 functions as the primary DC power conversion and distribution module within ABB automation systems. It receives a 24 V DC supply from the plant power network and converts it into a regulated 5 V DC output used to power sensitive electronic modules such as CPUs, communication interfaces, and I/O controllers. This ensures stable system operation and protects control components from voltage fluctuations.

In addition to power conversion, the module provides holdup capability (>20 ms at full load), allowing the system to maintain stable operation during brief power interruptions. Its regulated output and low ripple performance help ensure reliable data processing, communication integrity, and uninterrupted automation control in mission-critical applications.

Features

Converts 24 V DC input to 5 V DC output for control system power distribution.
Continuous output current of 6 A (30 W).
High efficiency of >85% for reduced energy loss and heat generation.
Low ripple and noise: <100 mV peak-to-peak for stable system operation.
Holdup time of >20 ms at full load for short power interruption protection.
Wide operating temperature range: -25°C to +70°C.
Storage temperature range: -40°C to +85°C.
Humidity tolerance: 5–95% RH (non-condensing).
Compact industrial-grade power supply design (5.1 kg).
Designed for continuous operation in harsh industrial environments.
High reliability for critical automation power systems.

Applications & Use Cases

Power supply for ABB distributed control systems (DCS).
Industrial automation and process control systems.
Power generation and utility control infrastructures.
Oil and gas production and refining facilities.
Chemical and petrochemical processing plants.
Water and wastewater treatment systems.
Factory automation and manufacturing control systems.
Supply of stable power to PLCs, CPUs, and I/O modules.
Communication and control system power stabilization.
Critical infrastructure requiring high-reliability DC power distribution.

System Compatibility

The ABB PHARPS32200000 is designed for integration within ABB industrial automation platforms and is compatible with:

ABB distributed control systems (DCS).
ABB AC 800M and related controller architectures.
ABB I/O modules and communication units requiring 5 V DC supply.
Industrial automation racks and control cabinets.
Standard 24 V DC industrial power distribution systems.
Process control and monitoring systems.
Existing ABB automation installations requiring regulated 5 V DC power.
Mission-critical control system electronics requiring stable low-voltage power.

Its high efficiency, strong electrical stability, and industrial-grade durability make the PHARPS32200000 a reliable core power supply solution for ABB automation and process control systems.
