Allen-Bradley 1492-XIM4024-16R master interface relay module In stock

Allen-Bradley 1492-XIM4024-16R master interface relay module In stock

Product Name:master interface relay module

Brand Name:Allen-Bradley

Model Number:1492-XIM4024-16R

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

allen bradley 1492 xim4024 16r master interface relay module in stock-1

Overview
Get your discount today
Specifications
Description
Applications
Environmental Strength
High-Resolution Measurement
FAQ
Spares
Recommended Products

Overview

Brand Name:	Allen-Bradley
Model Number:	1492-XIM4024-16R
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	1492-XIM4024-16R 16-point relay master interface module for industrial PLC output interfacing.
Product Type:	Master interface relay module with integrated relay outputs and field wiring terminals.
Relay Configuration:	16 SPDT relay outputs designed for PLC output isolation and field device switching.
Control Voltage:	20–26 V DC relay coil operating voltage for industrial automation applications.
Contact Rating:	Supports up to 16 A AC-1, 10 A resistive, and DC-13 switching ratings depending on application conditions.
Installation Method:	DIN rail mounting with removable terminal blocks, pre-wired cable connector, and relay status indicators.
Operating Environment:	Operating temperature 0°C to +60°C, humidity 5–95% RH non-condensing.
Dimension:	Width 83 mm × Height 230 mm × Depth 70.5 mm.
Weight:	Approx. 811 g (1.79 lb) shipping weight.

Description

1492-XIM4024-16R is an Allen-Bradley master interface relay module designed to simplify field wiring and improve signal isolation between PLC output modules and field devices. As part of the 1492-XIM interface module family, including 1492-XIM4024-8R, 1492-RXIM4024-16R, and 1492-XIM4024-16RF, it provides a dependable relay interface solution for modern industrial automation systems.

Featuring 16 relay outputs with 24 VDC control voltage, 1492-XIM4024-16R supports pre-wired cable connectivity, DIN rail installation, removable terminal blocks, and integrated relay status indicators. Its modular construction reduces installation time while improving maintenance efficiency and wiring organization.

Designed for demanding industrial control applications, 1492-XIM4024-16R delivers reliable switching performance, excellent electrical isolation, and broad compatibility with Allen-Bradley ControlLogix®, CompactLogix™, FLEX I/O™, and SLC™ automation platforms.

Applications

Power plants: Interfaces PLC outputs with relay-controlled auxiliary equipment, motor starters, and generator monitoring systems.
Substations: Provides reliable relay isolation for switchgear control, alarm circuits, and protection equipment.
Chemical plants: Simplifies field wiring for pumps, valves, solenoids, and process automation devices.
Steel mills: Supports heavy-duty relay switching in rolling mills, conveyor systems, and industrial production equipment.
Machinery manufacturing plants: Connects PLC outputs to robotic cells, packaging machines, automated assembly lines, and material handling systems.
Water treatment facilities: Controls pumps, blowers, chemical dosing systems, and distributed field devices through isolated relay outputs.

Environmental Strength

Operates reliably within a 0°C to +60°C industrial temperature range.
Supports 5–95% non-condensing humidity for demanding factory environments.
DIN rail mounting ensures secure installation in industrial control panels.
High-quality relay construction improves long-term operational durability.
Electrical isolation protects PLC outputs from field-side electrical disturbances.
Designed for continuous industrial automation and machine control applications.

High-Resolution Measurement

Integrated relay status indicators provide fast visual confirmation of output conditions.
Precision relay switching improves control signal accuracy and system response.
Low-contact resistance supports stable signal transmission to field devices.
Reliable isolation minimizes electrical noise between PLC outputs and external loads.
Compatible with pre-wired interface cables for consistent wiring quality.
Optimized relay architecture improves control reliability in high-density automation panels.

FAQ

Q1: What is 1492-XIM4024-16R used for?
A1: 1492-XIM4024-16R is a 16-point relay master interface module that connects PLC output modules to field devices while providing electrical isolation and simplified wiring.

Q2: Which PLC platforms are compatible with 1492-XIM4024-16R?
A2: The module supports various Allen-Bradley systems, including ControlLogix®, CompactLogix™, FLEX I/O™, SLC™, and other compatible I/O platforms using approved interface cables.

Q3: What control voltage does 1492-XIM4024-16R require?
A3: The relay module operates with a 20–26 V DC control voltage for reliable industrial switching applications.

Q4: Does 1492-XIM4024-16R include relay status indicators?
A4: Yes. Each relay channel includes a visual status indicator that simplifies troubleshooting and maintenance during system operation.

Q5: Why is 1492-XIM4024-16R beneficial in industrial control panels?
A5: It reduces field wiring complexity, improves electrical isolation, speeds installation with pre-wired cable support, and enhances long-term maintenance efficiency for PLC-based automation systems.
