Product Name: FLEX I/O-XT Thermocouple RTD mV Analog Input Module
Brand Name: Allen-Bradley
Model Number: 1794-IRT8XT
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Allen-Bradley 1794-IRT8XT FLEX I/O-XT Thermocouple RTD mV Analog Input Module |
| Manufacturer | Allen-Bradley |
| Product Type | FLEX I/O-XT Thermocouple RTD mV Analog Input Module |
| Part Number | 1794-IRT8XT |
| Weight | 0.1kg |
| Estimated shipping dimensions | 9.2x5.5x5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Number of inputs | 8 channels (2 groups of 4) |
| Input resolution | 14 bits |
| Open input detection time Immediate | detection (max 2 scans) |
| Common mode input range,min | +15V |
| Common mode rejection | -80 dB @ 5V peak-to-peak, 50…60 Hz |
| Accuracy vs. filter cutoff | 0.05% of full range in millivolt mode with filtering selected,Hardware only = 0.10% of full range in millivolt mode |
| Overvoltage capability | 15V DC continuous at 25 °C |
| Operating Temperature | -20…70 °C (-4…185 °F) |
| resistance range | 0…500 Ω |
| External DC Supply Current, Nom | 95 mA @ 24V DC |
| Power Dissipation, Max | 3 W @ 31.2V DC |
| Thermal Dissipation, Max | 10.2 BTU/hr @ 31.2V DC |
| Excitation current | 630 μA |
The Allen-Bradley 1794-IRT8XT is an 8-channel analog input module designed for precise temperature and low-level signal measurement in industrial automation systems. It supports thermocouple, RTD, resistance, and millivolt inputs, making it suitable for a wide range of process monitoring applications. As part of the FLEX I/O-XT platform, the module is built for harsh industrial environments, offering extended operating temperature capability, high measurement accuracy, and reliable signal acquisition for distributed control systems.
Acquires temperature and low-level analog signals from field devices.
Supports thermocouple, RTD, resistance, and millivolt input measurements.
Converts analog input signals into digital data for PLC processing.
Detects open sensor conditions for improved system diagnostics.
Provides high-resolution measurement for accurate process monitoring.
Supports distributed I/O installation to simplify field wiring.
Operates reliably in demanding industrial environments.
Compared with standard analog input modules, the Allen-Bradley 1794-IRT8XT offers broader sensor compatibility, enhanced environmental durability, and accurate temperature measurement, making it ideal for demanding industrial process applications.
