Product Name: RTD/TC Non-Isolated I/O module
Brand Name: Bently Nevada
Model Number: 133819-02
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
overview
| Product Name | RTD/TC Non-Isolated I/O module |
| Brand Name | Bently Nevada |
| Model Number | 133819-02 |
| Place of Origin | USA |
| Warranty | 12 months |
| Payment Methods | T/T |
| Shipment | DHL/UPS/EMS/Fedex... |
The Bently Nevada 133819-02 RTD/TC Non-Isolated I/O Module is a temperature monitoring interface designed for use with the 3500/61 monitoring system. It functions as an internal termination module, accepting input signals from RTD and thermocouple (TC) sensors and providing precise, real-time temperature measurements.
With six independent monitoring channels, the module supports flexible sensor configurations and integrates seamlessly into the 3500 rack system. It also includes built-in 4–20 mA recorder outputs for each channel, enabling continuous data transmission to external monitoring and control systems.
Accepts up to six RTD or thermocouple sensor inputs
Provides real-time temperature monitoring across six independent channels
Converts sensor signals into usable temperature data
Outputs 4–20 mA signals for recording and external system integration
Supports mixed sensor configurations (RTD and TC simultaneously)
Enables reliable temperature data acquisition for machinery protection systems
Supports Triple Modular Redundant (TMR) configurations for high reliability
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | Bently Nevada 133819-02 RTD/TC Non-Isolated I/O module |
| Manufacturer | Bently Nevada |
| Product Type | RTD/TC Non-Isolated I/O module |
| Part Number | 133819-02 |
| Dimensions | 2.3x11x24cm |
| Weight | 0.42kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Condition | New & Original in Factory Packing |
| Channel Configuration | Supports 6 independent temperature monitoring channels |
| Input Impedance | 10 MΩ for each lead input |
| Power Consumption | 3500/61: Nominal consumption of 9 watts |
| Input Signal | Accepts 1 to 6 RTD or TC transducer signals |
| Operating Temprature | -30°C to +65°C (-22°F to +150 °F) when used with Internal/External Termination I/O Modules |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Rack Space Requirements | 1 full-height rear slot |
| RTD Input Type | 2-, 3-, 4-wire, PT100, PT1000 (typical) |
| Thermocouple Input Type | J, K, T, E (standard) |
| Excitation Current (RTD) | 1 mA per channel (depends on configuration) |
| Input Voltage Range (TC) | ±50 mV to ±100 mV (depending on TC type) |
| Accuracy | ±0.1°C to ±0.5°C typical |
| Input Impedance | ≥1 MΩ (TC), ~100 Ω (RTD) |
Six-channel temperature monitoring capability
Compatible with RTD types (2-, 3-, 4-wire PT100, PT1000)
Supports standard thermocouples (J, K, T, E)
Integrated 4–20 mA recorder outputs for each channel
High input impedance (10 MΩ per lead) for accurate signal measurement
Flexible internal termination design for easy installation
Supports mixed sensor input configurations
Designed for use in TMR systems with voting mechanisms
Compact design occupying one full-height rear rack slot
Factory-new, original industrial-grade module
The Bently Nevada 133819-02 delivers high-accuracy temperature monitoring with typical measurement accuracy ranging from ±0.1°C to ±0.5°C. Its high input impedance ensures minimal signal distortion, improving measurement precision for both RTD and thermocouple inputs.
With a nominal power consumption of 9 watts, the module balances energy efficiency with reliable continuous operation. It operates effectively in harsh industrial environments, supporting temperatures from -30°C to +65°C and humidity levels typical of industrial settings.
The module’s integrated 4–20 mA outputs enhance efficiency by enabling direct communication with external systems, eliminating the need for additional signal conversion hardware. In TMR configurations, multiple modules provide redundancy and fault tolerance, ensuring uninterrupted operation and improved system reliability.
Q1: What input signal types does the Bently Nevada 133819-02 support?
A: The 133819-02 supports both RTD inputs (such as PT100 and PT1000) and thermocouple inputs (J, K, T, and E types).
Q2: What is the power consumption of the 133819-02?
A: The 133819-02 has a nominal power consumption of approximately 9 watts during normal operation.
Q3: What are the installation requirements for the 133819-02?
A: The Bently Nevada 133819-02 requires one full-height rear slot in the 3500 rack and is used as an internal termination I/O module.
Q4: What environmental conditions can the 133819-02 withstand?
A: The 133819-02 operates in temperatures from -30°C to +65°C and can be stored in conditions from -40°C to +85°C.
Q5: How does the 133819-02 ensure signal accuracy?
A: The 133819-02 uses high input impedance and stable excitation current to minimize signal distortion and maintain precise temperature measurements.
