Bently Nevada 140482-01 Prox/Velom I/O Module with External Terminations Ready For Ship

Bently Nevada 140482-01 Prox/Velom I/O Module with External Terminations Ready For Ship

Product Name:Prox/Velom I/O Module

Brand Name:BENTLY NEVADA

Model Number:140482-01

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

o module with external terminations ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	140482-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	140482-01
Product Type	Prox/Velom I/O Module with External Terminations
Compatible Monitor	3500/42M Proximitor Seismic Monitor
Supported Transducers	Prox/Accel, Velomitor, HTVS
Input Channels	4 Channels
Power Supply	-24 Vdc
Output Impedance	550 Ω
Operating Temperature	-30°C to +65°C
Storage Temperature	-40°C to +85°C
Humidity	95%, non-condensing
Frequency Response	0 to 10 kHz
Dimensions	2.5x11x24cm
Weight	0.4kg
Mounting Type	Rack-mounted
Signal Conditioning	Vibration, Velocity, Shaft Position

Description

140482-01 is a high-performance external termination I/O module designed for the Bently Nevada 3500/42M Proximitor Seismic Monitoring System. Engineered for demanding industrial environments, this module supports proximity probes, Velomitor sensors, and HTVS transducers for precise machinery vibration and shaft condition monitoring. 140482-01 helps improve rotating equipment reliability by delivering stable signal conditioning and advanced machine protection functions.

As part of the 3500/42M series, 140482-01, 140471-01, and 138700-01 provide flexible monitoring solutions for turbines, compressors, pumps, and critical rotating assets. The module supports external terminations, simplifying installation and maintenance in large-scale industrial systems while improving wiring accessibility.

With excellent EMC resistance, high measurement accuracy, and compatibility with multiple transducer types, 140482-01 is widely used in power generation, petrochemical processing, steel production, and automation industries requiring continuous vibration analysis and predictive maintenance support.

Applications

Power plants: Used for turbine vibration monitoring, shaft position analysis, and generator protection systems.
Oil & gas facilities: Supports compressor and pump condition monitoring in hazardous process environments.
Chemical plants: Enables continuous machinery health diagnostics and predictive maintenance programs.
Steel mills: Operates reliably under strong electromagnetic interference and high-temperature conditions.
Machinery manufacturing plants: Applied in rotating equipment monitoring for automated production systems.
Marine industry: Provides vibration surveillance for propulsion and auxiliary rotating equipment.
Water treatment facilities: Supports pump and motor vibration protection applications.

Features

Supports external termination configuration
Compatible with multiple seismic transducers
High-accuracy vibration signal conditioning
Integrated machinery protection capability
Excellent EMI/RFI resistance performance
Fast response alarm processing
Stable operation in industrial environments
Easy integration with 3500 monitoring racks

Functions

Monitors radial vibration signals
Measures shaft absolute vibration
Supports velocity and acceleration monitoring
Processes seismic transducer input signals
Provides alarm comparison and protection logic
Delivers buffered output for analysis systems
Enables predictive maintenance diagnostics

FAQ

Q1: What is the main function of the 140482-01 module?
A1: It provides vibration and seismic signal monitoring for rotating machinery within the 3500/42M system.

Q2: Which sensors are compatible with 140482-01?
A2: The module supports Prox/Accel probes, Velomitor sensors, and HTVS transducers.

Q3: Does 140482-01 support external terminations?
A3: Yes, this model is specifically designed with external termination connections.

Q4: What industries commonly use 140482-01?
A4: It is widely used in power generation, petrochemical, steel, marine, and manufacturing industries.

Q5: Can the module operate in harsh industrial environments?
A5: Yes, it is designed for reliable operation under vibration, EMI, and elevated temperature conditions.

Spares

Number	Description
176449-02	3500/42M Proximitor Seismic Monitor
128229-01	Prox/Seismic I/O Module with internal terminations
128240-01	Prox/Seismic I/O Module with external terminations
00530843	3500/42M Prox/Seismic I/O Module four-pin connector shunt
143489	3500/42M Monitor User Guide
135489-01	I/O Module with Internal Barriers, internal terminations, 4 x Prox/Accel
135489-02	I/O Module with Internal Barriers, internal terminations, 2 x Prox/Accel and 2 x Velomitor
135489-03	I/O Module with Internal Barriers, internal terminations, 4 x Velomitor
138708-01	Shaft Absolute I/O Module with internal terminations
138700-01	Shaft Absolute I/O Module with external terminations
00517018	3500/42M Shaft Absolute I/O Module 8-pin connector shunt
140471-01	Prox/Velom I/O Module with internal terminations
140482-01	Prox/Velom I/O Module with external terminations
00561941	3500/42M Prox/Velom I/O Module 10-pin connector shunt
00580434	Internal I/O Module connector header, Euro style, 8-pin
00580432	Internal I/O Module connector header, Euro style, 10-pin
00502133	Internal I/O Module connector header, Euro style, 12-pin
166M2389	Connector header Push-in-Spring Type (Alternative for PN 00580434)
166M2388	Connector header Push-in-Spring Type (Alternative for PN 00580432)
