Product Name:Cylinder Pressure I/O Module
Brand Name:Bently Nevada
Model Number:143729-01
Country of Origin:USA
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
143729-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Description |
|---|---|
| Model | 143729-01 |
| Product Type | Cylinder Pressure I/O Module |
| System | Bently Nevada 3500/77M |
| Channel Capacity | 4 channels |
| Input Type | 3rd-party pressure transducers (approved) |
| Frequency Response | 0 – 5.5 kHz |
| Input Impedance | 50 kΩ |
| Power Consumption | 7.8 W |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Dimension (Module) | 241.3 × 24.4 × 99.1 mm |
| Weight | Approx. 0.20 kg |
| Installation Slot | Rear rack full-height slot |
The 143729-01 Cylinder Pressure I/O Module is part of the Bently Nevada 3500/77M monitoring system, designed for advanced reciprocating compressor protection and cylinder pressure analysis. It processes input signals from approved third-party pressure transducers and converts them into accurate operational parameters for machine condition monitoring.
As part of the 3500/77M platform, including configurations such as 143729-01, the module delivers multi-channel signal conditioning for pressure-based measurements. It enables real-time evaluation of suction, discharge, and peak pressure behavior, supporting reliable machinery diagnostics in critical rotating and reciprocating equipment.
The system ensures continuous protection by comparing measured values against user-defined alarm thresholds. With internal termination design, the 143729-01 I/O module offers stable electrical integration, high accuracy signal processing, and dependable performance in industrial environments.
Q1: What is the main function of 143729-01 module?
A1: It processes cylinder pressure signals for reciprocating compressor monitoring and protection.
Q2: How many channels does the 143729-01 support?
A2: It supports up to 4 input channels for pressure transducers.
Q3: Is 143729-01 compatible with third-party sensors?
A3: Yes, it works with Bently approved third-party pressure transducers.
Q4: What system does this module belong to?
A4: It is part of the Bently Nevada 3500/77M Recip Cylinder Pressure Monitor system.
Q5: What type of installation does it require?
A5: It uses an internal termination rear rack slot installation configuration.
| Number | Description |
|---|---|
| 143729-01 | Cylinder Pressure I/O Module with internal terminations for Bently approved third-party pressure transducers |
| 143737-01 | Cylinder Pressure I/O Module with external terminations for Bently approved third-party pressure transducers |
| 00580434 | Internal I/O module connector header, Euro style, 8-pin, used on 143729-01 modules |
| 00580441 | Internal I/O module connector header, Euro style, 3-pin, used on 143729-01 modules |
| 146973-01 | Recip multi-event wheel kit |
| 145732-01 | Recip multi-event wheel |
| 146622-01 | Recip multi-event wheel stud |
| 165855-XX | Recip cylinder pressure transducer (refer to datasheet for details) |
| 283615 | MTL 7796+ external barrier (see field wiring drawing 147729) |
| 115M1270 | Custom band type, dual track |
| 114M1640 | Custom band type, single track |
| 111M8664-01 | Installation manual for band type |
| 166M4363 | Connector header, push-in spring type (alternative for PN 00580441) |
| 166M2389 | Connector header, push-in spring type (alternative for PN 00580434) |
