Product Name:SYSTEM MONITOR MODULE
Brand Name:Bently Nevada
Model Number:3300/01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3300/01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Model | 3300/01 System Monitor |
| Channels | Supports rack-wide monitoring |
| Power Input | Regulated DC from rack supply |
| Power Consumption | ~2–3.6 W (depending configuration) |
| Signal Input | Up to 2 Keyphasor signals |
| Input Impedance | 10 kΩ |
| Output Type | Buffered Keyphasor + system signals |
| Communication | Optional RS-232 / RS-422 serial |
| Dimensions | 241.3 × 24.4 × 241.8 mm |
| Weight | 0.91 kg |
| Mounting | Rack slot position 2 |
The3300/01 System Monitoris a central interface unit designed for the Bently Nevada 3300 machinery protection platform. It enables streamlined operator interaction with vibration and condition monitoring systems, supporting both standard and optional serial communication configurations. By centralizing rack communication functions,3300/01eliminates the need for external keypads or additional interface hardware, improving system simplicity and reliability.
In combination with related modules such as3300 System Monitorand rack power components, the unit delivers buffered signal access directly on the front panel. It also supports key functions like alarm reset, rack inhibit, and trip multiply control through contact closure inputs, ensuring flexible machine protection management.
The3300/01also integrates self-diagnostic capabilities and Keyphasor signal buffering, providing stable condition data output for predictive maintenance and industrial automation systems.
Q1: What is the main function of the 3300/01 System Monitor?
A1: It provides centralized rack monitoring, signal buffering, and alarm control for the 3300 machinery protection system.
Q2: Does the 3300/01 support communication with PLC or DCS systems?
A2: Yes, it supports optional RS-232 and RS-422 serial interfaces for industrial system integration.
Q3: Can the monitor operate without affecting system protection?
A3: Yes, it is non-critical to the protection path, so monitoring continues even if the module is offline.
Q4: What control functions are available on the 3300/01?
A4: It supports alarm reset, rack inhibit, and trip multiply functions via front panel or remote inputs.
Q5: What type of signals does the system handle?
A5A5: It processes Keyphasor signals and buffered monitoring data for vibration and machine condition analysis.
| Number | Description |
|---|---|
| RS-422 Rack-to-Rack Cable (84915) | RS-422 rack-to-rack communication cable (25-pin male to 25-pin female), available in multiple lengths from 10 ft (3 m) to 500 ft (150 m), assembled or non-assembled options |
| RS-232 Rack-to-Host Cable (25-pin) | RS-232 rack-to-host cable (25-pin female to 25-pin female), available in lengths from 10 ft (3 m) to 100 ft (30 m), assembled or non-assembled options |
| RS-232 Rack-to-Host Cable (15-pin) | RS-232 rack-to-host cable (15-pin male to 25-pin female), available in lengths from 10 ft (3 m) to 500 ft (150 m), assembled or non-assembled options |
| RS-422 Rack-to-Host Cable (84917) | RS-422 rack-to-host communication cable (25-pin female to 25-pin female), available in lengths from 10 ft (3 m) to 500 ft (150 m), assembled or non-assembled options |
