Bently Nevada 3300/03 System Monitor Ready For Ship

Bently Nevada 3300/03 System Monitor Ready For Ship

Product Name:System Monitor

Brand Name:Bently Nevada

Model Number:3300/03

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	3300/03
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	3300/03: System monitor communication interface with SDI and DDI data acquisition functions
Interface Type	SDI/DDI: Supports serial data and dynamic data collection from 3300 rack monitors
Communication Protocol	DF1 / Modbus: Compatible industrial communication standards for host system integration
Physical Interface	RS-232 / RS-422: Flexible serial communication options for industrial networks
Data Type	Static + Dynamic: Collects status, alarm, and vibration data from monitoring modules
Sampling Rate	1–15 seconds cycle: Supports fast trending and periodic data acquisition
Event Logging	Rack event list: Records alarm, status, and configuration change events with timestamps
Data Storage	Internal buffer memory: Stores static, alarm, and dynamic vibration datasets
Operating Temperature	Industrial grade: Suitable for control room and plant environments
Dimension	Standard 3300 rack slot module size, compact plug-in design for system integration
Weight	Approx. 0.5–1.0 kg depending on configuration and module options
Mounting Type	Rack-mounted: Installed directly in 3300 system monitor slot
Power Requirement	Backplane powered: Supplied directly from 3300 monitoring rack system

Description

The 3300/03 System Monitor is a modular communication interface designed to manage data exchange between a 3300 monitoring rack and external host systems. It integrates both Serial Data Interface (SDI) and Dynamic Data Interface (DDI) options, enabling flexible access to machine condition data in industrial environments.

Working alongside Bently Nevada monitoring platforms such as 3300 racks, the 3300/03 collects static values, alarm status, and dynamic vibration data from installed modules. It supports communication with systems like Allen-Bradley and Honeywell via RS-232 or RS-422 links using DF1 or Modbus protocols.

The 3300/03 SDI/DDI system is widely used in predictive maintenance and machinery diagnostics. It enables real-time data acquisition, event logging, and vibration analysis, making it suitable for turbines, compressors, and other critical rotating equipment.

Applications

Power plants: Used for turbine monitoring, generator vibration analysis, and protection system diagnostics.
Substations: Enables equipment condition monitoring, relay system support, and signal acquisition.
Chemical plants: Supports process automation, pump monitoring, and safety system integration.
Steel mills: Provides stable performance under high temperature, vibration, and electromagnetic interference environments.
Machinery manufacturing: Applied in automated production lines, rotating equipment monitoring, and diagnostic systems.

Features

Dual communication interface: SDI and DDI integration in one module
Supports RS-232 and RS-422 industrial communication standards
Compatible with Modbus and DF1 protocols
Fast data polling with 1–15 second update cycles
Event-driven diagnostic logging system

Functions

Collects static and dynamic machine condition data from 3300 racks
Transmits alarm and status information to host monitoring systems
Performs vibration data acquisition and buffering for diagnostics
Supports fast trending and historical data storage
Enables predictive maintenance and machinery health analysis

FAQ

Q1: What is the 3300/03 used for?
A1: The 3300/03 is used to interface 3300 monitoring racks with external host systems for data collection and diagnostics.

Q2: What is the difference between SDI and DDI?
A2: SDI collects static and status data, while DDI also captures dynamic vibration data for advanced analysis.

Q3: Which communication protocols are supported?
A3: It supports Modbus and Allen-Bradley DF1 protocols over RS-232 or RS-422 links.

Q4: Can the 3300/03 store event data?
A4: Yes, it maintains a timestamped event list including alarms, status changes, and system events.

Q5: Is the 3300/03 suitable for vibration monitoring?
A5: Yes, the DDI function supports dynamic vibration data collection for rotating machinery diagnostics.

Spares

135489-04	Relay output module, version 4
135613-01	Signal interface expansion card
135813-01	Motor control interface module
136188-01	Process monitoring relay board
136188-02	Process monitoring relay board, v2
136703-01	Digital I/O signal module
136711-01	Safety control relay card
136711-02	Safety control relay card, v2
136719-01	Digital I/O control module
138708-01	Analog signal interface card
139554-01	Process monitoring expansion unit
140471-01	Relay output control module
140471-02	Relay output control module, upgraded
140482-01	Motor driver interface board
143493-00-080-040-50-00	High-precision sensor interface unit
143729-01	Safety relay control module
146031-01	Digital control expansion board
146031-02	Digital control expansion board, upgraded
146055-10-02-00	Analog input/output monitoring card
