Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-00-03-10-02-05
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-03-10-02-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
330103-00-03-10-02-05 |
|
System Type |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 |
|
Total Length |
1.0 meter |
|
Cable Type |
Standard 75Ω triaxial cable |
|
Connector |
Miniature ClickLoc™ (standard) |
|
Material |
Stainless steel probe body |
|
Weight |
0.06kg |
|
Operating Temp |
-52°C to +177°C |
|
Cable Bend Radius |
25.4 mm |
|
Dimension |
1.8x1.5x113cm |
|
Unthreaded Length Option |
0MM |
|
Overall Case Length Option |
30MM |
|
Connector and Cable-Type Option |
Miniature coaxial ClickLoc connector, standard cable |
|
Agency Approval Option |
CSA, ATEX, IECEx Approvals |
330103-00-03-10-02-05is a high-performance 8 mm eddy current proximity probe designed for precision vibration and position monitoring in industrial machinery. As part of the3300 XL 8 mm Proximity Transducer System, it works with compatible extension cables and Proximitor sensors to deliver stable and accurate measurement output.
The system provides a voltage signal proportional to the distance between the probe tip and conductive target surface, supporting both dynamic vibration analysis and static position detection. It is widely used in turbine monitoring, rotating equipment protection, and speed sensing applications across heavy industries.
Built with robust materials and ClickLoc™ connectors,3300 XLprobes ensure reliable installation, strong mechanical durability, and long service life even in harsh operating environments.
Q1: What is the main use of 330103-00-03-10-02-05?
A1: It is used for vibration and position monitoring in rotating industrial equipment.
Q2: Is this probe compatible with 3300 XL systems?
A2: Yes, it is fully compatible with the 3300 XL Proximitor sensor and extension cables.
Q3: Can it operate in high-temperature environments?
A3: Yes, it supports operation from -52°C to +177°C.
Q4: What industries commonly use this probe?
A4: Power plants, steel mills, chemical plants, and machinery manufacturing industries.
Q5: Does it require special installation tools?
A5: No, the ClickLoc™ connector allows simple finger-tight installation without special tools.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing 12”x12”x6”, supports up to 8 Proximitor Sensors DIN-mount or 6 panel-mount, ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing 12”x8”x6”, supports up to 4 Proximitor Sensors DIN or panel mount, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing 13”x9.5”x7”, supports up to 8 DIN or 6 panel-mount sensors, ATEX Zone 0/1 and North American Division 1/2 certified |
| 02120015 | Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length customizable |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL system |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL system |
| 148722-01 | 3300 XL test plug with 3 test pins, color-coded 1-meter wires and banana plugs for sensor testing without wiring removal |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw kit, includes four 6-32 UNC screws per sensor |
| 03200006 | Silicone self-fusing tape 9.1 m roll for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables with tools |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools |
| 40180-02 | Connector protectors package containing 10 pairs for 3300 XL probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for extension cable environmental sealing |
| 03839420 | 75Ω triaxial female connector protector for probe lead and Proximitor sensor connection protection |
