Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-03-90-12-05
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-03-90-12-05 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model Number | 330103-00-03-90-12-05 |
| Product Type | 3300 XL 8 mm Proximity Probe |
| Measurement Technology | Eddy Current Proximity Sensing |
| Thread Type | M10 × 1 Metric Thread |
| Probe Diameter | 8 mm |
| Total Cable Length | 9.0 m (29.5 ft) |
| Cable Type | FluidLoc Cable |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Probe Case Material | AISI 303/304 Stainless Steel |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Operating Temperature | -52°C to +177°C |
| Tensile Strength | 330 N (75 lbf) |
| Agency Approvals | CSA, ATEX, IECEx |
| Weight | Approx. 0.32 kg (probe only) |
| Dimension | 8 mm probe diameter, M10 × 1 threaded housing, 9 m cable length |
The 330103-00-03-90-12-05 proximity probe is a key component of the renowned Bently Nevada 3300 XL 8 mm Proximity Transducer System, engineered for highly accurate shaft displacement, vibration, and position monitoring in rotating machinery. Designed with an M10 × 1 metric thread configuration, this probe delivers stable signal output and dependable performance in demanding industrial environments.
As part of the 3300 XL series, the 330103-00-03-90-12-05 probe features advanced eddy-current sensing technology that enables precise non-contact measurement of conductive targets. Its rugged stainless-steel construction, corrosion-resistant connectors, and FluidLoc cable design enhance durability while minimizing maintenance requirements in critical applications.
The 330103-00-03-90-12-05, together with compatible 3300 XL Proximitor Sensors and extension cables, provides a complete machinery protection solution for turbines, compressors, pumps, motors, and generators. The system supports API 670 compliance, excellent EMI/RFI immunity, and long-term measurement stability, making it an ideal choice for predictive maintenance and machine condition monitoring programs.
Power Plants: Turbine shaft vibration monitoring, generator rotor position measurement, overspeed protection systems, and machinery protection diagnostics.
Oil & Gas Facilities: Gas turbine condition monitoring, compressor vibration analysis, pump shaft displacement measurement, and critical rotating asset protection.
Petrochemical Plants: Process equipment health monitoring, high-temperature rotating machinery supervision, and predictive maintenance program support.
Steel Mills: Monitoring of large motors and rolling equipment, vibration detection in high-temperature and high-EMI environments, and continuous machinery reliability assessment.
Water & Hydropower Stations: Hydro turbine shaft position monitoring, generator condition analysis, and early fault detection for rotating assets.
Machinery Manufacturing Plants: Rotating equipment testing, dynamic vibration measurement, industrial automation monitoring, and production line performance optimization.
Q1: What is the primary function of the 330103-00-03-90-12-05 probe?
A1: It provides non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
Q2: Is the 330103-00-03-90-12-05 compatible with other 3300 XL components?
A2: Yes, it is designed for use with compatible 3300 XL Proximitor Sensors and extension cables.
Q3: What industries commonly use this proximity probe?
A3: Power generation, oil and gas, petrochemical, steel production, and industrial manufacturing sectors widely use this probe.
Q4: Does the probe support hazardous-area installations?
A4: Yes, the model includes CSA, ATEX, and IECEx approvals for certified industrial environments.
Q5: What advantages does the FluidLoc cable option provide?
A5: FluidLoc technology helps prevent fluid migration through the cable, improving reliability in oil-lubricated machinery applications.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual. |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing, 12” × 12” × 6”. Supports up to 8 Proximitor Sensors in DIN-mount configuration or 6 sensors in panel-mount configuration. Available with ATEX Zone 0 and Zone 1 certifications. |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing, 12” × 8” × 6”. Supports up to 4 3300 XL Proximitor Sensors in both DIN-mount and panel-mount configurations. Available with ATEX Zone 0 and Zone 1 certifications. |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing, 13” × 9.5” × 7”. Supports up to 8 Proximitor Sensors in DIN-mount configuration or 6 sensors in panel-mount configuration. Available with ATEX Zone 0, Zone 1, North American Division 1 and Division 2 certifications. |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire. Length specified in feet. |
| 138492-01 | Replacement panel-mount mounting pad. |
| 138493-01 | Replacement DIN-mount mounting pad. |
| 148722-01 | 3300 XL Test Plug with three color-coded 1-meter leads and banana plugs. Used for testing Proximitor Sensor performance without disconnecting field wiring. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor. |
| 03200006 | Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools. |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools used on 75Ω ClickLoc connectors. |
| 40180-02 | Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables. |
| 03839410 | 75Ω triaxial male connector protector for environmental protection of probe and extension cable connections. |
| 03839420 | 75Ω triaxial female connector protector for environmental protection of probe, extension cable, and Proximitor Sensor connections. |
