Overview

Brand Name:	Bently Nevada
Model Number:	330103-00-12-10-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Details
Model	330103-00-12-10-02-00
Type	3300 XL 8 mm Proximity Probe
Unthreaded Length Option	0 mm
Overall Case Length Option	120mm
Total Length Option	1.0 meter (3.3 feet)
Connector and Cable-Type Option	Miniature coaxial ClickLoc connector, standard cable
Agency Approval Option	Not required
Connector	Miniature ClickLoc, no protector
Probe Material	Stainless steel (SST) body
Weight	0.1kg
Dimention	1.8x1.6x105cm

Description

The 330103-00-12-10-02-00 3300 XL 8 mm Proximity Probe is a high-precision sensing element designed for industrial vibration and position monitoring systems. As part of the Bently Nevada 3300 XL series, it works in combination with the 3300 XL Proximitor Sensor (330104) and extension cable to form a complete eddy current transducer system for critical machinery diagnostics.

The 330103 probe delivers stable, non-contact measurement of shaft displacement, enabling accurate detection of both static position and dynamic vibration in rotating equipment such as turbines, compressors, and pumps. Its M10 x 1 threaded stainless-steel housing ensures secure installation in demanding environments.

Built for reliability and interchangeability, the 3300 XL 8 mm system supports long-term industrial monitoring with strong resistance to EMI/RFI interference and excellent mechanical durability for harsh operating conditions.

Applications

Power plants: Used for generator set status monitoring and relay protection
Substations: Enable bus differential control, line protection, and switchyard signal acquisition
Chemical plants: Integrate process automation and intrinsically safe monitoring systems
Steel mills: Operate reliably under high temperature and strong EMI conditions
Machinery manufacturing: Applied in robotic systems, automated lines, and packaging control

Features

High-accuracy non-contact vibration measurement
M10 x 1 threaded rugged probe design
Strong EMI/RFI immunity for industrial environments
Plug-and-play ClickLoc connector system
Compatible with 3300 XL sensor and cables
Stable long-distance signal transmission
Corrosion-resistant stainless steel housing
Designed for harsh temperature conditions
Interchangeable with 3300 XL system components

Functions

Measures shaft vibration in rotating machinery
Detects axial and radial displacement
Provides real-time condition monitoring signal
Supports Keyphasor and speed reference input
Converts distance change into proportional voltage output
Enables predictive maintenance diagnostics
Enhances machine protection systems
Works in continuous industrial monitoring setups
Ensures early fault detection in turbines and motors

FAQ

Q1: What is the 330103 probe used for?
A1: It is used for vibration and shaft position measurement in industrial rotating machinery systems.

Q2: Is the 330103 compatible with other 3300 XL components?
A2: Yes, it works with 3300 XL Proximitor Sensors and extension cables.

Q3: Can it operate in high-temperature environments?
A3: Yes, it supports temperatures up to 177°C in standard conditions.

Q4: What type of installation thread does it use?
A4: It uses an M10 x 1 industrial standard mounting thread.

Q5: Does it require special calibration?
A5: No, it is designed for interchangeability without bench calibration.

Spares

Number	Describe
141078	3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual
175751	3300 XL multi-purpose stainless steel housing 12"x12"x6", supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors, ATEX Zone 0/1 certified
176467	3300 XL stainless steel housing 12"x8"x6", supports up to 4 Proximitor sensors, DIN or panel mount, ATEX Zone 0/1 certified
330181	3300 XL stainless steel housing 13"x9.5"x7", supports up to 8 DIN or 6 panel sensors, hazardous area approved (ATEX Zone 0/1, Division 1/2)
02120015	Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified per order
138492-01	Replacement panel-mount mounting pad for Proximitor sensor installation
138493-01	Replacement DIN-mount mounting pad for Proximitor sensor installation
148722-01	3300 XL test plug with 3-pin adapter and color-coded leads for sensor diagnostics without removing wiring
04310310	3300 XL panel-mount screw, 6-32 UNC thread forming screw, 4 required per sensor
03200006	Silicone self-fusing tape (9.1 m roll) for connector protection and electrical insulation
40113-02	Connector protector kit for 3300 XL probes and extension cables, includes installation tools
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools
40180-02	Connector protectors set (10 pairs) for environmental sealing of probe and extension cable connections
03839410	75Ω triaxial male connector protector for extension cable-side protection
03839420	75Ω triaxial female connector protector for probe-side or sensor-side protection
04301007	3/8-24 probe lock nut with safety wire holes for secure mechanical locking
04301008	M10 x 1 probe lock nut with safety wire holes for secure installation
330153-01	3300 XL connector kit with ClickLoc connectors, sleeves, FEP tubing, and silicone tape
330153-09	ETR connector kit for high-temperature applications with heat-resistant components
163356	Connector crimp tool kit with inserts and installation tools, compatible with ClickLoc systems
