Bently Nevada 330103-00-15-10-02-00 3300 XL 8 mm Proximity Probes In stock

Bently Nevada 330103-00-15-10-02-00 3300 XL 8 mm Proximity Probes In stock

Product Name:3300 XL 8 mm Proximity Probes

Brand Name:BENTLY NEVADA

Model Number:330103-00-15-10-02-00

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330103 00 15 10 02 00 3300 xl 8 mm proximity probes in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330103-00-15-10-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	330103-00-15-05-01-00
Product Series	3300 XL 8 mm Proximity Probe
Thread Type	M10 × 1 Metric Thread
Probe Type	Non-contact Eddy Current Probe
Total Length	0.5 meter
Connector Type	Miniature coaxial ClickLoc connector with protector
Linear Range	2 mm (80 mils)
Frequency Response	0 to 10 kHz
Recommended Gap	-9 Vdc (approximately 1.27 mm / 50 mils)
Operating Temperature	-52°C to +177°C
Probe Material	AISI 303/304 Stainless Steel
Cable Insulation	FEP insulated triaxial cable
Dimension	1.8x1.5x112cm
Weight	0.1kg
Protection Features	RFI/EMI resistant design
Certifications	CE, RoHS, FCC, ATEX optional

Description

The Bently Nevada Bently Nevada 330103-00-15-05-01-00 belongs to the renowned 3300 XL 8 mm Proximity Transducer System, engineered for high-accuracy shaft vibration and position monitoring in rotating machinery. Designed with an M10 × 1 threaded probe body and durable industrial construction, this model delivers stable signal transmission for demanding turbine, compressor, and motor applications.

Compared with traditional eddy current probes, the 330103-00-15-05-01-00, 330103, and 330104 series offer enhanced EMI/RFI resistance, improved cable retention strength, and reliable long-distance monitoring performance. The integrated ClickLoc connector structure simplifies installation while helping reduce maintenance downtime in critical industrial systems.

The system supports seamless compatibility with other 3300 XL components, including Proximitor sensors and extension cables, allowing flexible configuration across API 670 compliant machinery protection systems. Its rugged mechanical design and dependable linear response make it suitable for continuous monitoring environments where vibration precision and operational reliability are essential.

Applications

Power plants: Used for steam turbine vibration monitoring, generator shaft position measurement, and predictive maintenance systems.
Oil & gas facilities: Supports compressors, pumps, and rotating equipment protection in hazardous environments.
Chemical plants: Provides stable proximity sensing for process-critical machinery and automation systems.
Steel mills: Ensures reliable vibration monitoring in high-temperature and heavy electromagnetic environments.
Paper mills: Monitors roll shafts, motors, and production line rotating assemblies.
Marine industry: Applied in propulsion systems and offshore rotating machinery monitoring.
Machinery manufacturing plants: Used in automated production equipment, motors, and industrial testing platforms.

Features

High-precision non-contact vibration measurement
Strong resistance to EMI and industrial interference
Rugged stainless steel probe construction
API 670 compliant monitoring performance
ClickLoc connectors for fast installation
Stable output over long cable distances
Compatible with multiple 3300 XL monitoring systems
Optional armored and FluidLoc cable versions available

Functions

Measures shaft vibration and axial position
Supports turbine and compressor condition monitoring
Provides Keyphasor and rotational speed reference signals
Delivers continuous machine protection data
Helps reduce unexpected equipment shutdowns
Enables predictive maintenance strategies
Supports integration with Bently Nevada monitoring racks

FAQ

Q1:What is the main use of the330103-00-15-05-01-00probe?
A1:It is mainly used for shaft vibration and position monitoring in rotating industrial machinery.

Q2:Is the330103-00-15-05-01-00compatible with other 3300 XL components?
A2:Yes, it is fully compatible with standard 3300 XL extension cables and Proximitor sensors.

Q3:Can this probe operate in high-temperature environments?
A3:Yes, the standard version supports temperatures up to +177°C, with extended temperature options available.

Q4:Does the probe support hazardous area installations?
A4:Yes, optional CSA, ATEX, and IECEx approvals are available for hazardous industrial applications.

Q5:What industries commonly use this proximity probe?
A5:Power generation, oil & gas, steel, chemical processing, marine, and heavy manufacturing industries widely use this model.

Spares

Number	Describe
148722-01	3300 XL test plug with 3 color-coded 1-meter wires and banana plugs for Proximitor sensor performance testing
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming mounting screw
03200006	Silicone self-fusing tape for connector insulation and environmental protection
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools
136536-01	Connector protector adapter for pre-1998 installation tools and 75Ω ClickLoc connectors
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables
03839410	75Ω triaxial male connector protector for environmental protection of extension cable connections
03839420	75Ω triaxial female connector protector for probe lead and Proximitor sensor connection protection
04301007	3/8-24 probe lock nut with safety wire holes for secure probe mounting
04301008	M10 × 1 probe lock nut with safety wire holes for secure installation
330153-01	3300 XL connector kit with male/female ClickLoc connectors, sleeves, FEP tubing, and silicone tape
