Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-02-12-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-02-12-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
330103-02-12-10-02-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 |
|
Armor |
Without armor |
|
Total Length |
1.0 m (typical “10” option) |
|
Case Length |
120 mm option |
|
Unthreaded Length |
20 mm configuration option |
|
Output Sensitivity |
7.87 V/mm (200 mV/mil) |
|
Linear Range |
0.25 – 2.3 mm |
|
Recommended Gap |
1.27 mm (50 mil) |
|
Operating Temp |
-52°C to +177°C |
|
Weight |
0.1kg |
|
Dimension |
1.8x1.6x105cm |
The330103-02-12-10-02-00belongs to the Bently Nevada 3300 XL 8 mm proximity probe series, designed for precise non-contact vibration and shaft position monitoring in rotating machinery. The330103model with M10 x 1 thread configuration delivers stable installation performance for industrial condition monitoring systems.
This eddy current proximity transducer is engineered to measure both dynamic vibration and static displacement in fluid-film bearing equipment. When integrated with the 3300 XL extension cable and Proximitor Sensor, it ensures accurate signal transmission and long-term operational stability.
The330103-02-12-10-02-00probe is widely used in turbine systems, compressors, pumps, and industrial automation environments where high reliability and measurement accuracy are critical for predictive maintenance and machine protection.
Q1: What is 330103-02-12-10-02-00 used for?
A1: It is used for non-contact vibration and shaft position monitoring in industrial rotating equipment.
Q2: Is 330103 compatible with 3300 XL systems?
A2: Yes, it is fully compatible with the Bently Nevada 3300 XL Proximitor Sensor system.
Q3: What industries use this probe?
A3: It is widely applied in power plants, refineries, steel mills, and manufacturing automation systems.
Q4: Does it support harsh environments?
A4: Yes, it is designed for high temperature, high vibration, and EMI-resistant industrial conditions.
Q5: What is the advantage of the 8 mm probe design?
A5: It provides rugged construction and reliable measurement accuracy in demanding machinery monitoring applications.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual. |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing (12”×12”×6”), supports up to 8 Proximitor Sensors in DIN-mount or 6 in panel-mount configuration, available with ATEX Zone 0 and Zone 1 certifications. |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing (12”×8”×6”), supports up to 4 Proximitor Sensors in DIN-mount and panel-mount configurations, available with ATEX Zone 0 and Zone 1 certifications. |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing (13”×9.5”×7”), supports up to 8 Proximitor sensors in DIN-mount or 6 in panel-mount configuration, with hazardous area approvals including ATEX Zone 0/1 and North American Division 1/2. |
| 02120015 | Bulk field wire: 1.0 mm² (18 AWG), 3-conductor, twisted shielded cable with drain wire. Length specified in feet. |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL system installations. |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL system installations. |
| 148722-01 | 3300 XL test plug with 3 color-coded wires and banana plugs for Proximitor sensor testing without removing field wiring. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw (6-32 UNC). Four screws required per sensor, supplied with housings. |
| 03200006 | Silicone self-fusing tape (9.1 m roll) for connector protection and environmental sealing. Not recommended for internal machine use. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools. |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors package (10 pairs) for 3300 XL 8 mm probes and extension cables, providing environmental sealing. |
| 03839410 | 75Ω triaxial male connector protector for extension cable side, used for environmental protection of connectors. |
| 03839420 | 75Ω triaxial female connector protector for probe lead or Proximitor sensor connection protection. |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure mechanical locking in probe installations. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for secure probe mounting in industrial applications. |
