Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-12-25-10-01-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-12-25-10-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Product Model |
330103-12-25-10-01-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 metric thread |
|
Measurement Type |
Non-contact eddy current sensing |
|
Output Signal |
Voltage proportional to gap distance |
|
Operating Temperature |
-52°C to +177°C |
|
Frequency Response |
0–10 kHz |
|
Linear Range |
Approx. 0.25 mm to 2.3 mm |
|
Cable Type |
75Ω triaxial shielded cable |
|
Connector Type |
ClickLoc gold-plated connector |
|
Material |
Stainless steel probe body |
|
Protection |
Industrial EMI/RFI resistant design |
|
Dimension (Probe Length) |
112x2x1.6cm |
|
Cable Length |
1–9 meters (config dependent) |
|
Weight |
0.14kg |
The 330103-12-25-10-01-00 3300 XL 8 mm Proximity Probe is designed for high-precision vibration and position monitoring in industrial rotating machinery. Based on the advanced 3300 XL proximity transducer architecture, it delivers stable and accurate non-contact measurement of shaft displacement in demanding environments such as turbines, compressors, and generators.
This probe integrates robust M10 x 1 threaded construction with reinforced mechanical design, ensuring reliable installation and long-term operational stability. It is fully compatible with 3300 XL extension cables and Proximitor sensor systems, supporting interchangeable configuration without the need for recalibration.
With superior resistance to temperature variation, electromagnetic interference, and mechanical stress, the 330103-12-25-10-01-00 ensures consistent signal integrity. It is widely used in predictive maintenance systems, helping operators enhance equipment reliability, reduce downtime, and optimize industrial asset performance.
Q1: What is the main use of 330103-12-25-10-01-00?
A1: It is used for non-contact vibration and position monitoring in rotating machinery.
Q2: Is it compatible with 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL Proximitor sensors and extension cables.
Q3: What industries use this probe?
A3: Power plants, petrochemical plants, steel mills, and manufacturing industries.
Q4: Can it work in high-temperature environments?
A4: Yes, it supports operation in temperatures up to +177°C.
Q5: Does it require calibration?
A5: No field calibration is required when used within compatible 3300 XL systems.
| Number | Describe |
|---|---|
| 148722-01 | 3300 XL test plug with 3-pin design and color-coded 1-meter wires terminated in banana plugs, used for checking Proximitor sensor performance through terminal test holes without removing field wiring. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming type, used for secure mounting of Proximitor sensors (4 screws required per unit). |
| 03200006 | Silicone self-fusing tape, 9.1-meter roll designed for electrical insulation and environmental protection of connectors; not recommended for internal machine casing use. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including installation tools and protective components for secure connector sealing. |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connector systems. |
| 40180-02 | Connector protectors package containing 10 pairs designed to provide environmental sealing and protection for probe and extension cable connectors. |
| 03839410 | 75Ω triaxial male connector protector designed for extension cable side, ensuring environmental sealing when connected to probe-side female protector. |
| 03839420 | 75Ω triaxial female connector protector used on probe leads or extension cables to protect connections and prevent environmental contamination. |
| 04301007 | 3/8-24 probe lock nut with dual safety wire holes, designed for secure mechanical fixation of proximity probes in industrial applications. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes, used to secure probe installation and prevent loosening under vibration conditions. |
