Bently Nevada 330104-00-10-05-01-05 8mm Proximity Probes In stock, China Bently Nevada 330104-00-10-05-01-05 8mm Proximity Probes In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330104-00-10-05-01-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	330104-00-10-05-01-05
Brand	Bently Nevada
Product Type	3300 XL 8 mm Proximity Probe
Thread Type	M10 x 1
Armor	Yes
Total Length	0.5 meter (1.6 ft)
Cable Type	Standard Cable with Connector Protector
Probe Diameter	8 mm
Case Material	AISI 303 / 304 Stainless Steel
Tip Material	PPS (Polyphenylene Sulfide)
Operating Temperature	-52°C to +177°C
Approx. Weight	0.1kg
Dimension	1.8x1.6x66cm

Description

Bently Nevada 330104-00-10-05-01-05 is a high-performance 3300 XL 8 mm proximity probe engineered for precise shaft vibration and axial position monitoring in rotating machinery. Designed with an M10 x 1 threaded stainless-steel case with armor, this model delivers dependable operation in turbines, compressors, motors, and pumps where continuous condition monitoring is critical.

As part of the trusted 3300 XL Series, 330104-00-10-05-01-05 features advanced eddy current sensing technology that converts target distance into a stable proportional voltage signal. Its rugged armored cable construction improves resistance to abrasion, oil exposure, and demanding industrial environments, making it ideal for heavy-duty installations.

Compatible with 3300 XL Proximitor Sensors and extension cables, 330104-00-10-05-01-05 offers easy integration with existing Bently Nevada monitoring systems. It supports high measurement accuracy, excellent temperature stability, and long-term reliability for predictive maintenance programs across power generation, petrochemical, and manufacturing sectors.

Applications

Power plants: Used for turbine shaft vibration monitoring, overspeed sensing, and generator rotor position supervision.
Oil & gas facilities: Installed on compressors, pumps, and steam turbines for predictive maintenance programs.
Chemical plants: Supports rotating equipment health monitoring in continuous process lines.
Steel mills: Provides vibration feedback for rolling mill motors, blowers, and heavy drive systems.
Machinery manufacturing plants: Applied in test benches, industrial motors, and automated machine diagnostics.
Marine industry: Suitable for propulsion turbines and auxiliary rotating assets.
Water treatment plants: Monitors pump shafts and drive equipment reliability.

Features

Advanced eddy current sensing technology
Rugged armored cable for harsh environments
M10 x 1 threaded stainless steel housing
High resistance to oil, dust, and vibration
Gold-plated ClickLoc connector system
Excellent linearity and signal stability
Compatible with 3300 XL monitoring systems
Reliable long service life

Functions

Measures shaft radial vibration
Detects axial shaft position movement
Supports speed / Keyphasor reference signals
Sends real-time displacement output signal
Helps prevent unexpected machinery failures
Improves maintenance scheduling efficiency
Enhances machine protection system accuracy

FAQ

Q1: What is the main use of 330104-00-10-05-01-05?

A1: It is mainly used for shaft vibration and position monitoring on rotating machinery.

Q2: Is this probe compatible with 3300 XL systems?
A2: Yes, it is designed for use with Bently Nevada 3300 XL Proximitor systems.

Q3: Does this model include armored cable protection?
A3: Yes, this version comes with armored cable for better mechanical durability.

Q4: What industries commonly use this probe?
A4: Power generation, oil & gas, steel, chemical, and manufacturing industries.

Q5: What thread type does this probe use?
A5: It uses an M10 x 1 threaded housing for secure installation.

Spares

Number	Describe
141078	3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual
175751	3300 XL Multi-Purpose Stainless Steel Housing, 12”x12”x6”, holds up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, ATEX Zone 0 / Zone 1 available
176467	3300 XL Multi-Purpose Stainless Steel Housing, 12”x8”x6”, holds up to 4 Proximitor Sensors in DIN-mount or panel-mount configuration
330181	3300 XL Multi-Purpose Stainless Steel Housing, 13”x9.5”x7”, holds up to 8 DIN-mount or 6 panel-mount Proximitor Sensors, hazardous area certified
02120015	Bulk field wire, 1.0 mm² (18 AWG), 3 conductor, twisted shielded cable with drain wire
138492-01	Replacement panel-mount mounting pad
138493-01	Replacement DIN-mount mounting pad
148722-01	3300 XL test plug with 3 color-coded 1-meter wires and banana plugs for sensor performance testing
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread forming screw
03200006	Silicone self-fusing tape, 9.1-meter roll for connector insulation and environmental protection
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools
136536-01	Connector protector adapter for pre-1998 installation tools with 75Ω ClickLoc connectors
40180-02	Connector protectors, package of 10 pairs for 3300 XL 8 mm probes and extension cables
03839410	75Ω triaxial male connector protector for extension cable environmental protection
03839420	75Ω triaxial female connector protector for probe lead or sensor connection protection
04301007	3/8-24 probe lock nut with safety wire holes
04301008	M10 x 1 probe lock nut with safety wire holes
330153-01	3300 XL connector kit with ClickLoc connectors, sleeves, FEP tubing, and silicone tape
330153-09	3300 XL ETR connector kit for high-temperature probes and extension cables
163356	Connector Crimp Tool Kit with inserts, instructions, and carrying case
