Bently Nevada 330104-00-13-10-02-05 3300XL 8 mm Proximity Probes , China Bently Nevada 330104-00-13-10-02-05 3300XL 8 mm Proximity Probes Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330104-00-13-10-02-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	330104-00-13-10-02-05
Series	3300 XL 8 mm Proximity Probe
Probe Type	Eddy current proximity probe
Thread Type	M10 x 1 metric thread
Total Length	1.0 meter system equivalent
Unthreaded Length	130 mm (configurable option)
Case Length	130 mm option configuration
Cable Type	Standard triaxial shielded cable
Connector Type	ClickLoc gold-plated connector
Material	Stainless steel probe body
Operating Temperature	-52°C to +177°C
Weight	0.14kg
Mounting	Machine radial/axial installation
Dimension	1.8x1.6x113cm

Description

The330104-00-13-10-02-05is part of the3300 XL 8 mm Proximity Probe series, designed for precise vibration and position monitoring in industrial rotating machinery. Working with the3300 XL Proximitor Sensorand extension cable, it delivers highly stable eddy current measurements for shaft displacement, axial movement, and Keyphasor-based speed detection in critical equipment.

The system supports both static and dynamic measurement outputs, making it suitable for turbine, compressor, and pump condition monitoring. It is fully compatible with otherBently Nevada 3300 XLcomponents, ensuring flexible installation and easy system integration without recalibration.

Built for harsh industrial environments, the330104-00-13-10-02-05offers strong mechanical durability, high temperature tolerance, and API 670-compliant performance, making it ideal for long-term predictive maintenance and machinery protection applications.

Applications

Power plants: Used for generator set vibration monitoring, shaft position tracking, and relay protection systems.
Substations: Enables busbar monitoring, transmission line protection, and switchgear condition detection.
Chemical plants: Supports process automation, equipment safety monitoring, and hazardous area signal measurement.
Steel mills: Ensures stable operation in high-temperature, high-interference environments with heavy machinery control.
Machinery manufacturing plants: Applied in automated production lines, robotics systems, and precision motion monitoring.

Features

High-accuracy eddy current displacement measurement
API 670 compliant design for industrial reliability
Interchangeable with 3300 XL system components
Rugged stainless steel probe construction
High resistance to vibration, oil, and contamination
ClickLoc connector for fast, secure installation
Extended temperature capability for harsh environments

Functions

Shaft vibration monitoring
Axial displacement measurement
Speed and Keyphasor signal detection
Machinery condition diagnostics
Predictive maintenance data support

FAQ

Q1: What is 330104-00-13-10-02-05 used for?
A1: It is used for vibration and shaft position measurement in rotating machinery monitoring systems.

Q2: Is the 330104-00-13-10-02-05 compatible with other 3300 XL systems?
A2: Yes, it is fully interchangeable with Bently Nevada 3300 XL 8 mm components.

Q3: What industries use this proximity probe?
A3: It is widely used in power plants, steel mills, chemical plants, and manufacturing automation systems.

Q4: Can it measure both vibration and position?
A4: Yes, it supports both dynamic vibration and static position monitoring of shafts.

Q5: Does it require calibration before installation?
A5: No, it is factory-calibrated and designed for direct plug-and-play integration.

Spares

Number	Describe
141078	3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual
175751	3300 XL Multi-Purpose Stainless Steel Housing 12x12x6, holds up to 8 Proximitor Sensors DIN or 6 panel mount, ATEX Zone 0/1 certified
176467	3300 XL Multi-Purpose Stainless Steel Housing 12x8x6, holds up to 4 Proximitor Sensors DIN or panel mount, ATEX Zone 0/1 certified
330181	3300 XL Multi-Purpose Stainless Steel Housing 13x9.5x7, supports up to 8 DIN or 6 panel-mounted sensors, hazardous area certified (ATEX Zone 0/1, North America Division 1/2)
02120015	Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified in feet
138492-01	Replacement panel-mount mounting pad
138493-01	Replacement DIN-mount mounting pad
148722-01	3300 XL test plug with 3-pin adapter and color-coded wires for sensor performance testing without removing field wiring
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC, set requires four screws per sensor
03200006	Silicone self-fusing tape 9.1 m roll for connector protection and electrical isolation
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables
03839410	75Ω triaxial male connector protector for extension cable environmental protection
03839420	75Ω triaxial female connector protector for probe lead and extension cable connections
04301007	3/8-24 probe lock nut with safety wire holes for secure installation
04301008	M10 x 1 probe lock nut with safety wire holes for secure fastening
330153-01	3300 XL connector kit including male/female ClickLoc connectors, sleeves, tubing, and silicone tape
330153-09	3300 XL ETR connector kit for high-temperature applications with ClickLoc connectors and insulation materials
163356	Connector Crimp Tool Kit with inserts and installation instructions, compatible with 330153 connector systems
