Bently Nevada 330104-00-25-10-02-00 3300 XL 8 mm Proximity Probe

Bently Nevada 330104-00-25-10-02-00 3300 XL 8 mm Proximity Probe

Product Name: 3300 XL 8 mm Proximity Probe

Brand Name: Bently Nevada

Model Number: 330104-00-25-10-02-00

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

bently nevada 330104 00 25 10 02 00 3300 xl 8 mm proximity probe-1

Overview
Commercial Terms
Description
Functions
Specifications
Advantage
Performance & Efficiency
Installation & Integration
Recommended Products

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Bently Nevada 330104-00-25-10-02-00 is a 3300 XL 8 mm proximity probe designed for precise vibration and position measurement in rotating machinery monitoring applications. Built with a robust M10 x 1 threaded body and a 1.0 meter (3.3 feet) total length configuration, the probe provides reliable performance in demanding industrial environments where accurate shaft displacement and vibration data are essential for machine protection and condition monitoring.

This model features a durable polyphenylene sulfide (PPS) probe tip and a nominal DC resistance of 7.59 ± 0.50 Ω, ensuring stable electrical characteristics and consistent signal output. Advanced mechanical enhancements such as TipLoc and CableLoc technologies improve structural integrity, with TipLoc strengthening the bond between the probe tip and body, and CableLoc providing high pull strength for secure cable retention. Optional FluidLoc cable protection further enhances reliability in environments exposed to oil or other fluids.

Functions

Measures shaft vibration in rotating machinery for condition monitoring and protection.
Monitors shaft position and displacement with high accuracy.
Provides stable proximity sensing between probe tip and conductive target surfaces.
Supports machinery diagnostic and predictive maintenance systems.
Enables early detection of mechanical issues such as imbalance, misalignment, and looseness.
Transmits accurate electrical signals through integrated probe and cable assembly.
Supports operation in fluid-exposed environments when equipped with FluidLoc cable option.
Contributes to continuous monitoring of critical industrial equipment.

Specifications

Product Name	Bently Nevada 330104-00-25-10-02-00 3300 XL 8 mm Proximity Probe
Manufacturer	Bently Nevada
Product Type	3300 XL 8 mm Proximity Probe
Part Number	330104-00-25-10-02-00
Weight	0.2kg
Estimated shipping dimensions	1.8x1.5x111cm
Place of shipment	Xiamen, China
Country of origin	USA
Minimum unthreaded length	0 mm
Overall Case Length Option	250 mm
Total Length Option	1.0 meter (3.3 feet)
Connector and Cable-Type Option	Miniature coaxial ClickLoc connector, standard cable
Agency Approval Option	Not required
Nominal Probe DC Resistance	7.59 ± 0.50 Ω
Probe Tip Material	Polyphenylene sulfide (PPS).

Advantage

Robust M10 x 1 threaded design ensures secure mechanical installation.
PPS probe tip provides high durability and resistance to harsh operating conditions.
TipLoc technology strengthens probe tip bonding for improved mechanical reliability.
CableLoc design delivers high pull strength (up to 330 N / 75 lbf) for enhanced cable security.
Optional FluidLoc protection prevents fluid ingress in harsh industrial environments.
Stable electrical performance with consistent DC resistance characteristics.
Compact and flexible 1.0 m design supports diverse installation requirements.
Compatible with proven Bently Nevada 3300 XL monitoring systems.
High reliability supports long-term machinery protection applications.
Designed for demanding industrial environments requiring continuous monitoring.

Performance & Efficiency

Delivers precise vibration and displacement measurements for rotating machinery analysis.
Maintains stable output with nominal DC resistance of 7.59 ± 0.50 Ω.
Ensures consistent signal quality through reinforced mechanical and electrical design.
Provides reliable performance under harsh industrial conditions, including fluid exposure when applicable.
Enhances diagnostic accuracy for predictive maintenance systems.
Supports efficient machinery protection by enabling early fault detection.
Improves operational reliability through secure probe tip and cable retention.
Optimized for integration within full 3300 XL 8 mm system architecture.

Installation & Integration

The Bently Nevada 330104-00-25-10-02-00 probe is designed for straightforward installation using its M10 x 1 threaded mounting interface, allowing secure attachment to a wide range of rotating machinery housings. It integrates seamlessly with Bently Nevada 3300 XL extension cables and Proximitor sensors, forming a complete proximity measurement system. The miniature coaxial ClickLoc connector ensures fast and reliable electrical connection, while the 1.0 meter cable length provides flexibility for routing in compact or complex installations. With optional FluidLoc protection and reinforced mechanical design features, the probe is well-suited for both new installations and retrofit applications in challenging industrial environments.
