Bently Nevada 330106-05-30-05-02-00 3300 XL 8 mm Reverse Mount Probes Original new, China Bently Nevada 330106-05-30-05-02-00 3300 XL 8 mm Reverse Mount Probes Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	330106-05-30-05-02-00
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	330106-05-30-05-02-00
Series	Bently Nevada 3300 XL 8 mm
Total Length Option	0.5 meter (1.6 feet)
Connector and Cable-Type Option	Miniature ClickLoc coaxial connector
Agency Approval Option	Not required
Output Signal	Voltage proportional to shaft distance
Target Material	Conductive metal surfaces (e.g., steel shaft)
Frequency Response	Suitable for vibration monitoring systems
Accuracy Standard	API 670 compliant system design
Connector Type	Gold-plated ClickLoc locking connectors
Installation Type	Panel mount / DIN rail compatible
Dimensions (W×H×D)	120 × 80 × 60 mm (sensor module approx.)
Weight	0.45 kg (system approx.)
Operating Temperature	-40°C to +85°C
Storage Temperature	-55°C to +100°C

Description

The330106-05-30-05-02-00 Proximity Transducer Systemis part of the advanced Bently Nevada 3300 XL 8 mm series, designed for high-precision vibration and position monitoring in rotating machinery. It integrates a probe, extension cable, and Proximitor sensor to deliver stable and accurate eddy current measurement signals.

The system, including models such as330106-05-30-05-02-00,330130, and the 3300 XL sensor platform, provides linear output proportional to shaft displacement. It supports both static and dynamic measurements, making it ideal for fluid-film bearing equipment and turbine monitoring applications.

Built for industrial reliability, the system ensures high interchangeability of components without recalibration. Its robust design, improved EMI/RFI resistance, and secure connector technology make it suitable for harsh environments while maintaining consistent performance in critical machinery protection systems.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enables bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Supports process automation and intrinsic safety monitoring.
Steel mills: Ensures stable operation under high temperature and strong EMI conditions.
Machinery manufacturing plants: Used for automated production lines and precision equipment monitoring.

Features

High-accuracy eddy current proximity measurement system
Fully interchangeable probe, cable, and sensor design
API 670 compliant performance standard
Strong EMI/RFI immunity for industrial environments
Secure ClickLoc connectors with vibration resistance

Functions

Measures shaft vibration and axial position in rotating machinery
Provides real-time monitoring of mechanical displacement
Supports Keyphasor and speed reference signal generation
Enables predictive maintenance for critical equipment
Ensures stable signal transmission in harsh industrial conditions

FAQ

Q1: What is 330106-05-30-05-02-00 used for?
A1: It is used for vibration and position monitoring in rotating machinery systems.

Q2: What systems is it compatible with?
A2: It is compatible with Bently Nevada 3300 XL proximity transducer systems.

Q3: Can it measure both vibration and position?
A3: Yes, it supports both static displacement and dynamic vibration measurement.

Q4: Is the system suitable for harsh environments?
A4: Yes, it is designed for industrial environments with EMI, heat, and mechanical stress.

Q5: Does it require calibration when replacing parts?
A5: No, its components are fully interchangeable without recalibration.

Spares

Number	Describe
141078	3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual
175751	3300 XL multi-purpose stainless steel housing 12"x12"x6", supports up to 8 DIN-mount or 6 panel-mount Proximitor sensors, ATEX Zone 0/1 certified
176467	3300 XL stainless steel housing 12"x8"x6", supports up to 4 Proximitor sensors, DIN or panel mount, ATEX Zone 0/1 certified
330181	3300 XL stainless steel housing 13"x9.5"x7", supports up to 8 DIN or 6 panel sensors, hazardous area approved (ATEX Zone 0/1, Division 1/2)
02120015	Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, length specified per order
138492-01	Replacement panel-mount mounting pad for Proximitor sensor installation
138493-01	Replacement DIN-mount mounting pad for Proximitor sensor installation
148722-01	3300 XL test plug with 3-pin adapter and color-coded leads for sensor diagnostics without removing wiring
04310310	3300 XL panel-mount screw, 6-32 UNC thread forming screw, 4 required per sensor
03200006	Silicone self-fusing tape (9.1 m roll) for connector protection and electrical insulation
40113-02	Connector protector kit for 3300 XL probes and extension cables, includes installation tools
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools
40180-02	Connector protectors set (10 pairs) for environmental sealing of probe and extension cable connections
03839410	75Ω triaxial male connector protector for extension cable-side protection
03839420	75Ω triaxial female connector protector for probe-side or sensor-side protection
04301007	3/8-24 probe lock nut with safety wire holes for secure mechanical locking
04301008	M10 x 1 probe lock nut with safety wire holes for secure installation
330153-01	3300 XL connector kit with ClickLoc connectors, sleeves, FEP tubing, and silicone tape
330153-09	ETR connector kit for high-temperature applications with heat-resistant components
163356	Connector crimp tool kit with inserts and installation tools, compatible with ClickLoc systems
