Product Name:3300 XL 8 mm Reverse Mount Probes
Brand Name:Bently Nevada
Model Number:330106-05-30-05-02-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330106-05-30-05-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330106-05-30-05-02-CN |
|
Series |
3300 XL 8 mm Reverse Mount Probe |
|
Thread Type |
M10 x 1 |
|
Total Length |
3.0 m system cable |
|
Connector Type |
Miniature ClickLoc coaxial |
|
Cable Type |
75Ω triaxial industrial cable |
|
Operating Temp |
-52°C to +177°C |
|
Extension Temp |
up to +260°C (ETR option) |
|
Weight |
0.06kg |
|
Dimension |
1x1x117cm |
The 330106-05-30-05-02-CN is part of the advanced Bently Nevada 3300 XL 8 mm Reverse Mount Probe series, designed for high-precision vibration and position monitoring in rotating machinery. It delivers stable eddy current measurement performance for fluid-film bearing systems, supporting both static and dynamic signal detection in demanding industrial environments.
The system works in combination with compatible 3300 XL extension cables and Proximitor sensors, ensuring accurate, drift-free signal transmission. Its reverse mount configuration provides flexible installation in compact mechanical layouts where conventional probe positioning is limited.
Engineered for harsh conditions, the 330106-05-30-05-02-CN offers strong resistance to temperature variation, electromagnetic interference, and mechanical stress. It is widely used in turbines, compressors, and critical rotating equipment where continuous condition monitoring is essential.
Q1: What is the 330106-05-30-05-02-CN used for?
A1: It is used for vibration and position monitoring in rotating industrial equipment.
Q2: Can it work in high-temperature environments?
A2: Yes, it supports up to 177°C standard and higher with extended temperature options.
Q3: Is it compatible with other 3300 XL components?
A3: Yes, it works with 3300 XL Proximitor sensors and extension cables.
Q4: What industries commonly use this probe?
A4: Power generation, petrochemical, steel, and manufacturing industries.
Q5: Does it support reverse mounting installation?
A5: Yes, it is specifically designed for reverse mount configurations in tight spaces.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing 12"x12"x6", supports up to 8 Proximitor sensors (DIN mount) or 6 sensors (panel mount), ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing 12"x8"x6", supports up to 4 Proximitor sensors for DIN and panel mounting, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing 13"x9.5"x7", supports up to 8 sensors (DIN) or 6 sensors (panel), hazardous area certified (ATEX Zone 0/1, Division 1/2) |
| 02120015 | Bulk field wire 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, customizable length |
| 138492-01 | Replacement panel-mount mounting pad for Proximitor sensor installation |
| 138493-01 | Replacement DIN-mount mounting pad for Proximitor sensor installation |
| 148722-01 | 3300 XL test plug with 3 color-coded leads and banana plugs for sensor performance testing without removing wiring |
| 04310310 | 3300 XL Proximitor sensor panel-mount screw, 6-32 UNC thread forming type, 4 screws required per sensor |
| 03200006 | Silicone self-fusing tape 9.1 m roll for connector insulation and environmental protection |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables with installation tools included |
| 136536-01 | Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors |
| 40180-02 | Connector protectors package (10 pairs) for 3300 XL 8 mm probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for environmental sealing of probe and extension cable connections |
