Bently Nevada 330106-05-30-20-02-CN 3300 XL 8 mm Reverse Mount Probes In stock

Bently Nevada 330106-05-30-20-02-CN 3300 XL 8 mm Reverse Mount Probes In stock

Product Name:3300 XL 8 mm Reverse Mount Probes

Brand Name:Bently Nevada

Model Number:330106-05-30-20-02-CN

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330106 05 30 20 02 cn 3300 xl 8 mm reverse mount probes in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330106-05-30-20-02-CN
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model	330106-05-30-20-02-CN
Product Type	Reverse Mount Proximity Probe
Thread Type	M10 x 1
Probe Diameter	8 mm
Total Length	2.0 meters (6.6 ft)
Connector Type	Miniature ClickLoc coaxial connector
Frequency Response	0 to 10 kHz
Linear Range	2 mm (80 mils)
Scale Factor	7.87 V/mm (200 mV/mil)
Operating Temperature	-52°C to +177°C
Probe Cable Type	75Ω triaxial FEP insulated cable
Probe Case Material	AISI 303/304 stainless steel
Connector Material	Gold-plated brass / beryllium copper
Recommended Gap	-9 Vdc (1.27 mm / 50 mils)
Weight	0.08kg
Minimum Shaft Diameter	50.8 mm (2 in)
Protection Standard	API 670 compatible
Agency Approval	CSA / ATEX / IECEx
Dimension	19.3x18.6x1.6cm

Description

Bently Nevada330106-05-30-20-02-CNis a high-reliability reverse mount proximity probe designed for demanding industrial vibration and shaft position monitoring applications. As part of the3300 XL 8 mm Proximity Transducer System, this model delivers accurate non-contact measurement for rotating machinery operating in turbines, compressors, motors, pumps, and generators. The M10 x 1 threaded construction and 2.0-meter cable configuration provide flexible installation in limited mounting spaces.

Built with advanced eddy current sensing technology,330106-05-30-20-02-CNoffers excellent linearity, temperature stability, and electromagnetic interference resistance. It works seamlessly with3300 XL Proximitor Sensorsand extension cables, supporting both static position and dynamic vibration monitoring in critical equipment protection systems.

Compared with earlier non-XL series probes, the330106-05-30-20-02-CN,330105, and related3300 XLmodels feature enhanced mechanical durability, improved connector security, and superior environmental sealing. The gold-plated ClickLoc connectors and rugged stainless-steel construction help ensure dependable long-term operation in harsh industrial environments while meeting API 670 machinery protection requirements.

Applications

Power plants: Used for turbine shaft vibration monitoring, generator protection, and rotor position measurement.
Oil & gas facilities: Supports compressors, pumps, and critical rotating equipment condition monitoring.
Steel mills: Provides reliable vibration feedback in high-temperature and heavy electromagnetic interference environments.
Chemical plants: Enables continuous machinery health diagnostics and predictive maintenance systems.
Paper mills: Monitors high-speed rollers, motors, and process machinery stability.
Water treatment plants: Applied in pump and motor vibration supervision systems.
Machinery manufacturing plants: Integrates with automated equipment, rotating spindles, and industrial production lines.

Features

High-precision non-contact eddy current sensing
Reverse mount design for compact installations
Excellent resistance to EMI and RFI interference
Rugged stainless-steel probe housing
Gold-plated ClickLoc connectors for secure connections
API 670 compliant transducer system performance
Compatible with 3300 XL extension cables and Proximitor sensors
Stable operation under harsh industrial temperatures
Strong cable pull resistance and improved mechanical durability

Functions

Measures shaft vibration and displacement
Detects rotor movement and mechanical instability
Provides real-time shaft position monitoring
Supports machinery protection and predictive maintenance
Supplies dynamic and static vibration measurement signals
Helps prevent unexpected rotating equipment failures
Improves operational safety and maintenance efficiency

FAQ

Q1:What is the main function of the330106-05-30-20-02-CNprobe?
A1:It is used for non-contact vibration and shaft position monitoring in rotating machinery.

Q2:Is the330106-05-30-20-02-CNcompatible with older 3300 systems?
A2:Yes, it is backward compatible with many non-XL 3300 series components.

Q3:What industries commonly use this proximity probe?
A3:Power generation, oil & gas, steel, chemical processing, and manufacturing industries widely use it.

Q4:Does the probe support hazardous area approvals?
A4:Yes, this model supports CSA, ATEX, and IECEx certifications.

Q5:What connector type is used on this model?
A5:It uses a miniature ClickLoc coaxial connector with secure locking performance.

Spares

Number	Describe
03200006	Silicone self-fusing tape. 9.1-meter (10-yard) roll designed for connector protection, offering excellent electrical insulation and environmental sealing. Easy to apply, but not recommended for use inside machine housings.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and required installation tools.
136536-01	Connector protector adapter enabling compatibility with pre-1998 installation tools for 75Ω ClickLoc connectors.
40180-02	Connector protectors package containing 10 pairs for 3300 XL 8 mm probes and extension cables, ensuring environmental sealing of connectors.
03839410	75Ω triaxial male connector protector designed for installation on extension cables to provide environmental protection at connection points.
03839420	75Ω triaxial female connector protector used on probe leads and extension cables to shield connections from environmental exposure.
04301007	3/8-24 probe lock nut with dual safety wire holes for secure mechanical fastening of probe assemblies.
04301008	M10 x 1 probe lock nut with safety wire holes designed to ensure stable probe installation and vibration resistance.
330153-01	3300 XL connector kit including male/female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for probe and cable assembly.
