Product Name:3300 5mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330171-00-08-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330171-00-08-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Model |
330171-00-08-10-02-00 |
|
Probe Type |
3300 5mm Proximity Probe |
|
Thread |
1/4-28 UNF |
|
Total System Length |
5.0 m (16.4 ft) |
|
Linear Range |
2.0 mm (80 mil) |
|
Recommended Gap |
1.27 mm (50 mil) |
|
Operating Temperature |
-35°C to +177°C |
|
Weight |
0.02kg |
|
Material |
Stainless steel (SST) + PPS tip |
|
Output Type |
Eddy current analog signal |
|
Cable Type |
Shielded coaxial system |
|
Connector |
Gold-plated ClickLoc |
|
Dimension |
0.8x111.1x0.8cm |
The 330171-00-08-10-02-00 3300 5mm Proximity Probe is engineered for precise vibration and position monitoring in compact machinery environments. As part of the Bently Nevada 3300 XL series, it delivers reliable eddy-current measurement performance for fluid-film bearing systems where installation space is limited.
Built with a compact 5mm sensing tip, the 330171-00-08-10-02-00 provides stable signal output when used with compatible 3300 XL extension cables and Proximitor sensors. Its design ensures consistent linear response across a defined measurement range, supporting both static shaft position and dynamic vibration detection.
The 330171-00-08-10-02-00 is optimized for small clearance applications such as compressors and tight mechanical assemblies. It offers improved mechanical durability, ClickLoc connection reliability, and enhanced resistance to industrial contaminants, making it suitable for continuous condition monitoring in demanding environments.
Q1: What is the main use of 330171-00-08-10-02-00?
A1: It is used for measuring shaft vibration and position in compact rotating machinery systems.
Q2: Is 330171-00-08-10-02-00 compatible with 3300 XL systems?
A2: Yes, it works with 3300 XL extension cables and Proximitor sensors.
Q3: What environments can it operate in?
A3: It is suitable for industrial environments with temperatures from -35°C to +177°C.
Q4: Does it support vibration and position measurement?
A4: Yes, it measures both dynamic vibration and static shaft position.
Q5: Is special calibration required for installation?
A5: No, it supports interchangeability without individual calibration requirements.
| Number | Description |
|---|---|
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable used for Proximitor Sensor to monitor connections. |
| 03200006 | Silicone self-fusing tape, 9.1 m (10 yard) roll for connector protection, providing insulation and environmental sealing. Not recommended inside machine casing. |
| 40113-03 | Connector Protector Kit for 3300 5mm probes, including connector protectors and installation tools. |
| 136536-01 | Connector Protector Adapter, enables compatibility of pre-1998 connector protector kits with ClickLoc extension cable connectors. |
| 40180-03 | Connector Protectors package, contains 10 pairs of 75Ω coaxial connector protection sets for environmental sealing. |
| 03839410 | 75Ω triaxial / 95Ω coaxial male connector protector, installed on extension cable to protect probe connections from environmental exposure. |
| 03800001 | 75Ω coaxial female connector protector, installed on 3300 5mm probe lead to ensure sealed connection with extension cable protector. |
| 163356 | Connector Crimp Tool Kit including multi-connector inserts and installation instructions; compatible with 330153 connector kits and ClickLoc systems. |
