Product Name:3300 5mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330173-07-11-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330173-07-11-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
330173-07-11-10-02-00 |
|
Series |
3300 5mm Proximity Probe |
|
Probe Diameter |
5 mm |
|
Thread Type |
1/4-28 UNF |
|
Total Length Options |
0.5 m / 1.0 m / 2.0 m / 5.0 m / 9.0 m |
|
Connector Type |
Miniature ClickLoc (with protector option) |
|
Cable Type |
Armored triaxial FEP insulated |
|
System Length |
5 m or 9 m typical configuration |
|
Dimension |
1.5x116.1x1.2cm |
|
Weight |
0.04kg |
|
Operating Temp |
-35°C to +177°C |
|
Linear Range |
0.25 mm – 2.3 mm |
330173-07-11-10-02-00is a 3300 5mm proximity probe designed for precise vibration and position monitoring in industrial machinery. As part of the Bently Nevada 3300 series system, it works with compatible extension cables and Proximitor sensors to deliver stable, high-accuracy output proportional to target distance.
The330173-07-11-10-02-00probe is engineered for demanding environments where compact installation and reliable signal integrity are essential. It supports both static and dynamic measurement, making it suitable for critical rotating equipment condition monitoring.
With armored construction and ClickLoc connector design,330173-07-11-10-02-00ensures strong mechanical protection, stable electrical performance, and long service life. It is widely used in turbines, compressors, and industrial rotating systems requiring continuous condition monitoring.
Q1: What system is compatible with 330173-07-11-10-02-00?
A1: It is compatible with Bently Nevada 3300 XL Proximitor Sensor and extension cable systems.
Q2: What is the main use of this proximity probe?
A2: It is used for vibration and shaft position measurement in rotating machinery.
Q3: Can it operate in harsh environments?
A3: Yes, the armored design supports high temperature and industrial vibration conditions.
Q4: Does it support dynamic vibration monitoring?
A4: Yes, it measures both static displacement and dynamic vibration signals.
Q5: Is special calibration required for installation?
A5: No, it supports interchangeability without individual calibration requirements.
| Number | Description |
|---|---|
| 02120015 | Bulk field wire 1.0mm² (18 AWG), 3-conductor, twisted, shielded cable for connections between Proximitor Sensor and monitor. |
| 03200006 | Silicone self-fusing tape, 9.1-metre (10-yard) roll, used for connector protection, electrical isolation, and environmental sealing. Not recommended for internal machine casing use. |
| 40113-03 | Connector Protector Kit for 3300 5mm probes, including connector protectors and installation tools. |
| 136536-01 | Connector Protector Adapter enabling compatibility of pre-1998 connector protector kits with ClickLoc extension cable connectors. |
| 40180-03 | Connector Protectors package containing 10 pairs of 75Ω coaxial connector protectors. |
| 03839410 | 75Ω triaxial / 95Ω coaxial male connector protector for extension cable, designed for environmental protection of connectors. |
| 03800001 | 75Ω coaxial female connector protector for 3300 5mm probe leads, used with male protector for connector environmental sealing. |
| 163356 | Connector Crimp Tool Kit including multi-connector inserts and installation instructions, compatible with 330153 connector kits or ClickLoc systems. |
