Product Name: 3300 XL 8 mm Probe
Brand Name: Bently Nevada
Model Number: 330195-02-12-05-CN
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| 3300 XL 8 mm Reverse Mount Probe | Pump Condition Monitoring Probe |
| Extended Temperature Proximity Probe | Rotating Machinery Sensor |
| Eddy Current Displacement Probe | Noncontact Displacement Probe |
| Shaft Vibration Sensor | API 670 Compatible Probe |
| Industrial Condition Monitoring Probe | Fluid Film Bearing Monitoring Probe |
| Reverse Mount Configuration Probe | Stainless Steel Probe Housing |
| High Temperature Machinery Probe | PPS Probe Tip Sensor |
| Turbine Monitoring Probe | Proximitor Compatible Probe |
| Compressor Vibration Probe | Predictive Maintenance Sensor |
| High Reliability Vibration Probe | Harsh Environment Industrial Probe |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 330195-02-12-05-CN 3300 XL 8 mm Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Probe |
| Part Number | 330195-02-12-05-CN |
| Estimated shipping dimensions | 1.3x1.2x69cm |
| Weight | 0.04kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Total Length Option | 0.5 meter (1.6 feet) |
| Output resistance | 50 Ω |
| Probe dc resistance (nominal) (RPROBE) table | 7.45 ± 0.50 ohms |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
The Bently Nevada 330195-02-12-05-CN is a 3300 XL 8 mm extended temperature range reverse mount proximity probe designed for precise vibration and position monitoring in harsh industrial environments. It provides noncontact eddy current measurement of shaft displacement, enabling accurate detection of both static and dynamic behavior in rotating machinery such as turbines, compressors, pumps, and generators.
This model features a compact reverse mount design with D3/8-24 UNF threads, making it suitable for installations with limited space or specific orientation requirements. It is engineered with a 0.5-meter cable and delivers stable electrical performance with a nominal probe resistance of 7.45 ± 0.50 Ω, ensuring reliable signal transmission when paired with compatible 3300 XL extension cables and Proximitor® sensors.
Built for extreme operating conditions, the probe supports elevated temperature ranges up to 177°C at the tip and 260°C for cable and connector sections. Its stainless steel housing and PPS probe tip provide strong mechanical durability and environmental resistance, while patented TipLoc and CableLoc technologies enhance structural integrity and cable retention strength.
The 330195-02-12-05-CN probe operates as a passive eddy current sensor and does not require any software, firmware, or electronic programming. Its function is based entirely on electromagnetic coupling between the probe tip and the conductive target surface.
It is installed as part of a complete measurement chain consisting of the probe, extension cable, and Proximitor® sensor. Proper mechanical installation, including correct mounting torque, alignment, and connector engagement, is essential for accurate and stable signal transmission.
Each probe is assigned to a single measurement channel within the monitoring system and is used for vibration or position measurement of a specific machine location. It operates directly within Bently Nevada 3300 XL system architecture without requiring any configuration steps.
The probe is factory-calibrated and designed for standardized integration across compatible systems. Measurement accuracy depends on correct installation conditions and mechanical setup rather than any programmable parameters or software settings.
