Bently Nevada 330854-080-24-00 3300 XL 25 mm Extension Cable

Bently Nevada 330854-080-24-00 3300 XL 25 mm Extension Cable

Product Name: 3300 XL 25 mm Extension Cable

Brand Name: Bently Nevada

Model Number: 330854-080-24-00

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

bently nevada 330854 080 24 00 3300 xl 25 mm extension cable-1

Overview
Ways to contact
Specifications
Introduction
Main Functions
Features
Monitoring & Control
FAQ
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Winnie
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Ways to contact

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Bently Nevada 330854-080-24-00 3300 XL 25 mm Extension Cable
Manufacturer	Bently Nevada
Product Type	3300 XL 25 mm Extension Cable
Part Number	330854-080-24-00
Weight	0.28kg
Estimated shipping dimensions	20x20x2cm
Place of shipment	Xiamen, China
Country of origin	USA
Cable Length Option	080=8.0 metres (26.2 feet)
Armor and Cable Option	24=High Temperature FluidLoc cable
Agency Approval Option	00=No Approvals
Extension Cable Material	75 Ω triaxial, perfluoroalkoxyethylene (PFA) insulated FluidLoc cable.
Extension Cable Armor (optional)	Flexible AISI 302 SST with PFA outer jacket.
Operating and Storage Temperature	-35°C to +200°C (-31°F to +392°F)

Introduction

The Bently Nevada 330854-080-24-00 is an 8.0-meter (26.2 ft) 3300 XL 25 mm extension cable specifically designed for high-performance machinery condition monitoring systems. It is an essential component of the Bently Nevada 3300 XL 25 mm proximity transducer system, which is widely used for monitoring shaft position and differential expansion (DE) in large rotating equipment such as steam turbines, gas turbines, compressors, and generators.

The 330854-080-24-00 is engineered to ensure highly stable and noise-resistant signal transmission between proximity probes and monitoring instrumentation. Its 75 Ω triaxial FluidLoc construction with PFA insulation provides excellent electrical integrity while also preventing internal fluid migration, which is critical in environments exposed to oil mist, hydrocarbons, or other industrial process fluids.

In differential expansion measurement systems, the 330854-080-24-00 enables precise tracking of axial movement by supporting multi-probe configurations that monitor turbine rotor and casing movement relative to thrust bearings or reference points. This makes the 330854-080-24-00 a critical part of predictive maintenance and machinery protection strategies, helping operators detect thermal growth, misalignment, or abnormal mechanical behavior at an early stage.

Main Functions

Provides signal transmission between proximity transducers and monitoring systems
Supports differential expansion (DE) measurement applications in rotating machinery
Maintains stable signal integrity over long distances
Enables accurate axial movement and thermal growth monitoring in turbines and compressors
Ensures compatibility with the 3300 XL 25 mm system

Features

Designed for Bently Nevada 3300 XL 25 mm Proximity Transducer System
Fixed cable length: 8.0 meters (26.2 feet) for standardized installation in machinery monitoring setups
Uses 75 Ω triaxial FluidLoc cable architecture for stable, low-noise signal transmission
PFA (perfluoroalkoxyethylene) insulation provides strong resistance to high temperature, chemicals, and industrial contaminants
FluidLoc technology prevents fluid migration along the cable, improving long-term reliability in oil-rich or harsh process environments
Rated operating and storage temperature: −35°C to +200°C (−31°F to +392°F), suitable for extreme thermal conditions
Optional AISI 302 stainless steel armor with PFA outer jacket for enhanced mechanical protection against vibration and abrasion
High signal integrity support for differential expansion (DE) and shaft position measurement applications
Engineered for demanding industrial environments such as turbines, compressors, and rotating machinery systems
Supports long-term stability and accuracy in critical condition monitoring and protection systems

Monitoring & Control

The 330854-080-24-00 plays a critical role in Differential Expansion (DE) monitoring systems, where it supports precise measurement of axial movement in rotating machinery.

Typical applications include:

Monitoring turbine shaft thermal expansion
Tracking compressor rotor axial displacement
Supporting dual-probe or dual-ramp measurement configurations
Enhancing predictive maintenance and machinery protection systems

By ensuring stable signal transmission, the 330854-080-24-00 helps maintain accurate data for vibration, position, and expansion analysis in high-risk industrial assets.

FAQ

Q1: What is the 330854-080-24-00 used for?
A: The 330854-080-24-00 is used as an extension cable in the 3300 XL 25 mm proximity transducer system, primarily for differential expansion (DE) measurement in rotating machinery.

Q2: What is the length of the 330854-080-24-00 cable?
A: The 330854-080-24-00 cable has a fixed length of 8.0 meters (26.2 feet).

Q3: What temperature range can the 330854-080-24-00 handle?
A: The 330854-080-24-00 operates reliably in a temperature range of −35°C to +200°C (−31°F to +392°F).

Q4: What type of cable construction does the 330854-080-24-00 use?
A: The 330854-080-24-00 uses a 75 Ω triaxial FluidLoc cable with PFA insulation, designed to resist high temperatures and prevent fluid ingress.

Q5: Does the 330854-080-24-00 have mechanical protection options?
A: Yes, the 330854-080-24-00 can include an optional AISI 302 stainless steel armor with a PFA outer jacket for enhanced mechanical durability in harsh environments.
