Bently Nevada 330880-28-45-020-03-02 PROXPAC XL Proximity Transducer Original new

Bently Nevada 330880-28-45-020-03-02 PROXPAC XL Proximity Transducer Original new

Product Name:PROXPAC XL Proximity Transducer

Brand Name:Bently Nevada

Model Number:330880-28-45-020-03-02

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330880 28 45 020 03 02 proxpac xl proximity transducer original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330880-28-45-020-03-02
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	330880-28-45-020-03-02, PROXPAC XL Proximity Transducer Assembly with integrated 3300 XL 8 mm sensing technology.
Product Type:	Integrated proximity transducer assembly for shaft vibration and position monitoring.
Probe System:	Includes a 3300 XL 8 mm proximity probe with integrated Proximitor® sensor and 1 m probe cable.
Linear Range:	Provides a 2 mm (80 mil) linear measurement range for precise displacement monitoring.
Output Sensitivity:	Standard scale factor of 7.87 V/mm (200 mV/mil) with excellent measurement stability.
Frequency Response:	Supports signal frequencies from 0 to 10 kHz with field wiring up to 305 m (1000 ft).
Environmental Protection:	PPS housing rated IP66 and Type 4X, suitable for demanding industrial environments.
Operating Temperature:	Probe operating temperature from -52°C to +177°C; housing and sensor from -52°C to +100°C.
Dimensions:	Overall dimensions depend on selected standoff adapter and probe penetration options, configurable to suit installation requirements.
Weight:	Approximately 1.44 kg (3.2 lb) with a typical 0.3 m (12 in) sleeve configuration.

Description

The Bently Nevada 330880-28-45-020-03-02 is a PROXPAC XL Proximity Transducer Assembly designed for accurate shaft vibration and position measurement in rotating machinery. Integrating a 3300 XL 8 mm proximity probe and Proximitor® sensor into a single compact housing, it eliminates the need for a separate extension cable or external sensor enclosure, simplifying installation and reducing wiring complexity.

As part of the 3300 XL monitoring series, 330880-28-45-020-03-02 features a rugged PPS housing with IP66 and Type 4X environmental protection, delivering reliable operation in harsh industrial environments. The assembly provides stable linear output, excellent electromagnetic performance, and compatibility with long-distance field wiring for dependable condition monitoring.

Designed for critical asset protection, 330880-28-45-020-03-02 is widely used in power generation, oil & gas, petrochemical processing, compressors, turbines, pumps, and other rotating equipment where continuous vibration monitoring and predictive maintenance are essential.

Applications

Power plants: Used for steam turbine shaft vibration monitoring, rotor displacement measurement, and predictive maintenance.
Substations: Monitor rotating auxiliary equipment, cooling pumps, and motor shaft conditions for reliable operation.
Chemical plants: Provide continuous vibration monitoring for compressors, agitators, and critical process pumps.
Steel mills: Measure shaft position and vibration on rolling mills, large motors, and heavy-duty rotating machinery operating in harsh industrial environments.
Oil & gas facilities: Monitor gas turbines, centrifugal compressors, pumps, and pipeline equipment for machinery protection.
Machinery manufacturing plants: Integrate with condition monitoring systems for high-speed spindles, industrial gearboxes, and automated production equipment.

Features

Integrated 3300 XL probe and Proximitor® sensor.
Eliminates external extension cable requirements.
Rugged PPS housing with IP66 and Type 4X protection.
Excellent linearity for precision shaft measurements.
Supports long-distance field wiring up to 305 m.
High resistance to vibration, moisture, and harsh environments.
Compatible with hazardous-area installations.
Designed for continuous machinery condition monitoring.

Functions

Measures shaft vibration with high accuracy.
Monitors axial position and radial displacement.
Supplies continuous proximity signals to protection systems.
Detects abnormal machine movement for predictive maintenance.
Supports critical rotating equipment health monitoring.
Reduces installation complexity with integrated sensor design.
Improves equipment reliability through continuous condition monitoring.

FAQ

Q1: What is the primary function of 330880-28-45-020-03-02?
A1: It is an integrated proximity transducer assembly designed to monitor shaft vibration and position in rotating machinery.

Q2: Does 330880-28-45-020-03-02 include a built-in Proximitor® sensor?
A2: Yes. The assembly integrates both the 3300 XL 8 mm proximity probe and the Proximitor® sensor into one compact housing.

Q3: What environmental protection rating does 330880-28-45-020-03-02 provide?
A3: It features an IP66 and Type 4X rated housing for reliable operation in harsh industrial environments.

Q4: Which industries commonly use 330880-28-45-020-03-02?
A4: It is widely used in power generation, oil & gas, petrochemical processing, mining, steel production, and other industries operating critical rotating equipment.

Q5: Can 330880-28-45-020-03-02 be used for predictive maintenance?
A5: Yes. It delivers continuous shaft vibration and position data that supports machinery protection strategies and predictive maintenance programs.

Spares

Number	Description
148722-01	3300 XL Test Plug with three color-coded 1-meter leads and banana plugs for testing Proximitor Sensor performance without disconnecting field wiring.
04310310	3300 XL Proximitor Sensor panel-mount screw, 6-32 UNC thread-forming type. Four screws required per sensor installation.
03200006	Silicone self-fusing tape, 9.1 m (10 yd) roll, providing electrical insulation and environmental protection for connectors.
40113-02	Connector Protector Kit for 3300 XL 8 mm probes and extension cables, including connector protectors and installation tools.
136536-01	Connector protector adapter for compatibility with pre-1998 installation tools used with 75Ω ClickLoc connectors.
40180-02	Package containing 10 pairs of connector protectors for 3300 XL 8 mm probes and extension cables.
03839410	75Ω triaxial male connector protector for extension cable connections, providing environmental protection against moisture and contaminants.
03839420	75Ω triaxial female connector protector for probe and extension cable connections, providing environmental sealing and connector protection.
04301007	3/8-24 probe lock nut with dual safety-wire holes for secure probe mounting in vibration-prone applications.
04301008	M10 × 1 probe lock nut with dual safety-wire holes for secure installation and retention of proximity probes.
330153-01	3300 XL Connector Kit containing male and female ClickLoc connectors, color-coded sleeves, FEP tubing, and silicone tape for cable termination and maintenance.
