Bently Nevada 3500/40M 125680-01 Proximitor I/O Module Original new, China Bently Nevada 3500/40M 125680-01 Proximitor I/O Module Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Bently Nevada
Model Number:	125680-01
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Description	Value
Model	125680-01
Channels	4-channel input monitoring
Input Type	Proximity transducer signals
Power Consumption	7.7 W
Input Impedance	10 kΩ
Output Type	Buffered transducer outputs (coaxial)
Accuracy	±0.33% typical, ±1% max full scale
Rack Requirement	1 full-height slot
Weight	0.91 kg
Dimension	241.3 × 24.4 × 241.8 mm

Description

The Bently Nevada™ 3500/40M Proximitor Monitor features a 4-channel design, tailored to receive input signals from dedicated Bently Nevada proximity sensors. It optimizes raw sensor signals to deliver diversified vibration and position data, then cross-checks processed readings against custom alarm thresholds set on-site.

Operators can configure individual channels of the 3500/40M via the 3500 Rack Configuration Software to activate a full range of monitoring tasks:

Radial vibration detection
Thrust position tracking
Eccentricity measurement
Differential expansion monitoring
REBAM monitoring function

Applications

Power plants: Used for generator set vibration monitoring and protection.
Substations: Supports turbine and rotating equipment signal acquisition.
Chemical plants: Process machinery vibration and safety monitoring.
Steel mills: High-temperature rotating machinery condition monitoring.
Machinery manufacturing: Precision equipment vibration control and diagnostics.

Features

4-channel independent monitoring capability
Multiple vibration measurement functions (radial, thrust, eccentricity)
High-precision signal conditioning (±0.33% typical accuracy)
Programmable alarm setpoints and delays
Buffered transducer outputs with short-circuit protection
Advanced digital filtering and frequency response control
Rack-based modular design for easy expansion

Cores of Operation

This monitoring module is engineered to fulfill two core operational demands for industrial equipment:
1. Real-time equipment safeguarding: It continuously tracks key operating parameters and compares them with preset alarm limits to trigger timely alert responses.
2. Intuitive operational data output: It supplies actionable machine health data to assist both field operators and maintenance teams in daily work.
Based on on-site configuration settings, each channel will process incoming signals and output multiple stable measured indicators, known as static parameters. Users are allowed to set independent alert limits for every enabled static parameter, while critical danger thresholds can be assigned to up to two selected static indicators as required.
