Product Name:3500/94 VGA Display
Brand Name:Bently Nevada
Model Number:3500/94 145988-01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
3500/94 145988-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
3500/94 VGA Display System (145988-01) |
|
Module Type |
Display + I/O Interface Module |
|
Power Consumption |
4.6 W max |
|
Operating Temperature |
-30°C to +65°C |
|
Storage Temperature |
-40°C to +85°C |
|
Humidity |
95% non-condensing |
|
Module Weight |
0.74kg |
|
I/O Module Weight |
0.34 kg |
|
Display Type |
VGA Touch Screen Industrial Monitor |
|
Communication |
RS232 / VGA / Network Interface |
|
Dimensions (Module) |
2.5x25x24cm |
|
Dimensions (I/O) |
241.3 × 24.4 × 99.1 mm |
|
Mounting Distance |
Up to 10 m from rack |
3500/94 145988-01 VGA Display System is an advanced industrial visualization solution designed for Bently Nevada 3500 machinery protection platforms. It integrates a VGA display module, I/O interface card, and touch-screen monitor to deliver real-time monitoring of vibration, alarm, and system status data. The operator can access all diagnostic information through an intuitive touch menu, ensuring efficient machine condition awareness.
The system supports multiple display configurations, including API-670 compatible rack views, alarm event lists, and customizable screens for machine train monitoring. With flexible local configuration, users can tailor display layouts such as 1X vibration trends, gap readings, or full system summaries according to operational requirements.
With support for remote mounting up to 10 meters and optional multi-rack access via Display Router Box, 3500/94 145988-01 ensures reliable industrial performance in power plants, refineries, and manufacturing environments where continuous condition monitoring is critical.
Q1: What is 3500/94 145988-01 used for?
A1: It is used for industrial machinery monitoring and vibration data visualization in Bently Nevada 3500 systems.
Q2: Can it display multiple racks?
A2: Yes, it supports up to four racks using an optional Display Router Box.
Q3: Is the system touch-screen based?
A3: Yes, it uses an industrial VGA touch-screen interface for operation.
Q4: What industries use this module?
A4: It is widely used in power plants, refineries, steel mills, and manufacturing facilities.
Q5: Can the display be customized?
A5: Yes, users can configure up to nine custom screens locally.
| Number | Describe |
|---|---|
| 145988-01 | 3500/94 VGA Display Module, industrial touch-screen visualization unit for Bently Nevada 3500 system, used to display system events, alarms, and machine data in real time. |
| 147663-01 | 3500/94 I/O Module, rear-mounted interface card providing communication, VGA output, RS232 touch control, and system data transmission functions. |
| 149356-01 | Display Router Box, multi-rack switching unit enabling up to 4 3500 racks to share one display with alarm status indication and rack selection control. |
| 102M8950 | RS PowerStation / Advantech-compatible industrial display monitor, touch-screen VGA interface used for 3500/94 system visualization in industrial environments. |
| 148638-01 | Serial touch cable (25 ft), used for connecting 3500/94 I/O module to touch display for control signal transmission. |
| 148637-01 | VGA extension cable (20 ft), used to transmit video signals between 3500/94 module and external display monitor. |
