Product Name: Standard Proximity Probe
Brand Name: Bently Nevada
Model Number: 76680-00-06-50-0-2
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Bently Nevada 76680-00-06-50-0-2 Standard Proximity Probe |
| Manufacturer | Bently Nevada |
| Product Type | Standard Proximity Probe |
| Part Number | 76680-00-06-50-0-2 |
| Estimated shipping dimensions | 20x20x5.2cm |
| Weight | 0.82kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Unthreaded Length Option | Minimum unthreaded length: 0 mm = 0 0 |
| Case Length Option | Order in increments of 06 mm = 0.6 |
| Total Length Option | 5.0 metres (16.4 ft) = 50 |
| Armor Option | Without armor = 0 |
| Connector Option | With miniature coaxial male connector = 2 |
| Operating Temperature | -18°C to +177°C (0°F to +350°F) |
| Storage Temperature | -34°C to +177°C (-29°F to +350°F) |
| Probe Tip Material | Molded thermoplastic |
| Probe Case Material | 300 series stainless steel |
The Bently Nevada 76680-00-06-50-0-2 is a high-performance 35 mm standard proximity probe designed for accurate differential expansion (DE) measurement in medium and large steam turbines. As part of a complete Proximity Transducer System, it works together with an extension cable and Proximitor® Sensor to provide reliable shaft position and vibration monitoring in demanding industrial environments.
This model features a 5.0 m total cable length, miniature coaxial male connector, and rugged stainless steel construction suitable for high-temperature applications above 125°C (257°F). The probe uses 95 Ω coaxial FEP-insulated cable for stable signal transmission and supports direct connection to the Proximitor® Sensor, simplifying installation and reducing wiring complexity.
Its molded thermoplastic probe tip and 300 series stainless steel case ensure durability, corrosion resistance, and long-term operational stability in harsh turbine environments.
High-Temperature Capability
Operates reliably from -18°C to +177°C, making it ideal for steam turbine environments and other harsh industrial conditions.
Durable Construction
The 300 series stainless steel housing offers excellent corrosion resistance and mechanical strength, while the molded thermoplastic tip improves durability.
Simplified Installation
The 5 m integral cable can connect directly to the Proximitor® Sensor, eliminating the need for additional extension cables.
Stable Signal Transmission
Uses 95 Ω coaxial FEP-insulated cable with optimized resistance characteristics for accurate and stable measurements.
Flexible Mounting Options
Supports threaded, unthreaded clamp mounting, and rear- or side-exit cable configurations for versatile installation.
Reliable Industrial Performance
Designed specifically for critical rotating equipment applications where precision and reliability are essential.
The Bently Nevada 76680-00-06-50-0-2 delivers highly accurate and stable differential expansion and vibration measurements for steam turbines and other critical rotating machinery. Its advanced 95 Ω coaxial FEP-insulated cable design ensures consistent signal transmission with minimal interference, even across long cable distances. The probe maintains precise monitoring capability under continuous industrial operation, helping improve machinery protection and operational reliability.
Designed for harsh environments, the probe operates efficiently in temperatures ranging from -18°C to +177°C (0°F to +350°F). The combination of a molded thermoplastic probe tip and durable 300 series stainless steel housing provides excellent resistance to heat, corrosion, vibration, and mechanical stress. This robust construction reduces maintenance requirements and supports long-term performance in demanding turbine applications.
1. What is the main application of the 76680-00-06-50-0-2?
The 76680-00-06-50-0-2 is primarily used for differential expansion and vibration monitoring in medium and large steam turbines, helping ensure safe and reliable machinery operation.
2. Can the 76680-00-06-50-0-2 operate in high-temperature environments?
Yes. The 76680-00-06-50-0-2 is designed for high-temperature industrial applications and can operate in temperatures ranging from -18°C to +177°C (0°F to +350°F).
3. Does the 76680-00-06-50-0-2 require a separate extension cable?
No. The 76680-00-06-50-0-2 features a 5-metre integral cable that can connect directly to a Proximitor® Sensor, simplifying installation and reducing wiring requirements.
4. What materials are used in the 76680-00-06-50-0-2?
The 76680-00-06-50-0-2 uses a molded thermoplastic probe tip and a 300 series stainless steel housing for excellent durability, corrosion resistance, and long-term industrial performance.
5. What type of connector is included with the 76680-00-06-50-0-2?
The 76680-00-06-50-0-2 is equipped with a miniature coaxial male connector for secure and stable signal transmission.
6. Is the 76680-00-06-50-0-2 suitable for harsh industrial environments?
Yes. The 76680-00-06-50-0-2 is specifically designed for demanding industrial environments with high temperatures, vibration, and continuous operating conditions.
