Product Name:991 Thrust Transmitter
Brand Name:Bently Nevada
Model Number:991-06-70-01-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
991-06-70-01-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Product Model |
991-06-70-01-00 |
|
Product Type |
Thrust Transmitter |
|
Input Signal |
3300 NSv Proximity Probe |
|
Output Signal |
4–20 mA DC (2-wire loop powered) |
|
Full Scale Range |
0.6-0-0.6 mm |
|
System Length |
7.0 meters (23 ft) |
|
Mounting Type |
DIN rail / bulkhead options |
|
Operating Voltage |
+12 to +35 VDC |
|
Operating Temperature |
-35°C to +85°C |
|
Storage Temperature |
-51°C to +100°C |
|
Humidity |
0–100% condensing |
|
Weight |
0.46kg |
|
System Weight |
0.82 kg |
|
Dimensions |
7.3x5.9x9.9cm |
The 991-06-70-01-00 thrust transmitter is a compact loop-powered monitoring device designed for accurate axial displacement measurement in rotating machinery. It is widely applied in OEM compressor, pump, and fan systems where a simplified 4–20 mA output is required for control integration.
The system works with the 3300 NSv proximity probe and extension cable, converting mechanical shaft thrust into a stable proportional current signal. This allows direct connection to PLC or DCS platforms for real-time protection logic and condition monitoring in industrial environments.
Built for reliability in harsh operating conditions, the 991-06-70-01-00 includes integrated signal conditioning, diagnostic output support, and stable performance across temperature variations, making it suitable for compact machinery installations with limited space.
Q1: What is the main function of the 991-06-70-01-00?
A1: It converts axial shaft displacement into a standard 4–20 mA signal for machinery control systems.
Q2: Which probe is compatible with this transmitter?
A2: It is designed to work with the 3300 NSv proximity probe and extension cable system.
Q3: Can it be used in harsh environments?
A3: Yes, it supports high humidity, vibration, and industrial temperature conditions.
Q4: What mounting options are available?
A4: It supports DIN rail clips and bulkhead screw mounting configurations.
Q5: Is it suitable for OEM applications?
A5: Yes, it is commonly used in compressors, pumps, motors, and fan OEM systems.
| Number | Describe |
|---|---|
| 123266-01 | Coaxial Cable Kit, includes 4 cables, each 1.5 m (5 ft) |
| 02211505 | Single coaxial cable, 1.5 m (5 ft) length |
| 01810700 | 9V alkaline battery for test adapter |
| 02270056 | AC adapter, universal input 108–132 Vac / 207–253 Vac, 9 Vdc output |
| 02198937 | North American AC power cord |
| 123133 | User guide for 990/991 Test Adapter |
| 02173006 | Bulk shielded cable, 1.0 mm² (18 AWG), 2-conductor for 4–20 mA loop and PROX OUT |
| 123655 | Installation guide for 990/991 transmitter systems |
| 330153-05 | Cable connector kit with 75 Ω connectors, shrink tubing, and isolator seal |
