Product Name:Electric Driven TK-3e
Brand Name:Bently Nevada
Model Number:TK-3E 177313-02-01
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
TK-3E 177313-02-01 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
TK-3E 177313-02-01 |
|
System Type |
Proximity system calibration test kit |
|
Input Power |
95–125 Vac / 190–250 Vac, 50/60 Hz |
|
Current Requirement |
Minimum 1A |
|
Vibration Range |
50–254 μm (2–10 mil p-p) |
|
Speed Range |
0–5000 cpm ±1000 cpm |
|
Spindle Range |
0–25.4 mm (0–1000 mils) |
|
Material (Target/Wobble Plate) |
AISI 4140 alloy steel |
|
Dimensions (H×W×D) |
30x25x20cm |
|
Weight |
5.14kg |
|
Operating Temperature |
0°C to 50°C |
|
Storage Temperature |
-18°C to 65°C |
|
Humidity |
Up to 95% non-condensing |
|
Protection Rating |
IP54 (closed environment use) |
The TK-3E 177313-02-01 Proximity System Test Kit is designed for accurate simulation of shaft vibration and position signals used in calibration of Bently Nevada monitoring systems. It helps technicians validate both monitor performance and the overall health of proximity transducer loops, ensuring reliable measurement accuracy in condition monitoring applications.
The TK-3E 177313-02-01 utilizes a precision spindle micrometer assembly with a universal probe holder compatible with 5 mm to 19 mm probes. This allows controlled displacement of the target toward the probe tip in calibrated steps, enabling precise voltage verification through a Proximitor output reading.
In addition, the TK-3E 177313-02-01 includes a motor-driven wobble plate for vibration simulation, enabling field calibration without complex instrumentation, improving maintenance efficiency and diagnostic consistency.
Q1: What is the TK-3E used for?
A1: It is used to simulate shaft vibration and position signals for calibration of proximity monitoring systems.
Q2: Which probe sizes are compatible?
A2: The system supports probe diameters from 5 mm to 19 mm.
Q3: Does it require complex instruments for testing?
A3: No, it can verify vibration output without an oscilloscope using built-in simulation mechanisms.
Q4: What type of vibration range does it simulate?
A4: It generates vibration signals from 50 to 254 μm peak-to-peak.
Q5: Is it suitable for field use?
A5: Yes, it is designed for portable field calibration with a stable magnetic base and rugged structure.
