Product Name: Genius Block I/O Module
Brand Name: General Electric
Model Number: IC660BBD025
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IC660BBD025 Genius Block I/O Module |
| Manufacturer | General Electric |
| Product Type | Genius Block I/O Module |
| Part Number | IC660BBD025 |
| Weight | 1.44kg |
| Estimated shipping dimensions | 9x11x22.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Block to block Isolation | 850V |
| Required DC power | 150 mA typical/300 mA maximum |
| Power supply dropout time | 4 ms at 12 volts, 20 ms at 24 volts |
| 5 VDC supply | 0-0.8 VDC |
| 12 VDC supply | 0-4 VDC |
| 24 VDC supply | 0-6 VDC |
| Input impedance (typical) | 3.3K Ohms |
| Input processing time (typical) | 1.4 ms |
| Maximum output current (steady state) | 0.5 Amps per circuit |
| Maximum inrush current | 4 Amps up to 10ms |
| Block output current (total) | 16 Amps |
| Output OFF leakage current | 10µA, maximum |
| Output turn-on delay | 0.5 ms, maximum |
| Output voltage drop | 2.0 volts maximum at 4 Amps inrush |
| Output Diagnostics | Switch Fault |
| Operating Temperature | -0° to +60°C (32° to +140°F) |
| Storage Temperature | -40 °C (-40° to +212°F) |
| Humidity | 5% to 95% (non-condensing) |
| Distributed I/O Module | GE Genius Series |
| GE Field I/O Module | Industrial Fieldbus I/O |
| Industrial Automation I/O Block | Remote I/O Block |
| Factory Automation Module | Machine Control I/O Module |
| Genius Network Module | High-Density I/O Block |
| PLC Remote I/O Module | GE Control System Component |
| GE Automation Hardware | Industrial Networking I/O Module |
| Industrial Control Interface | PLC Expansion I/O Device |
| Digital Input Output Module | Industrial Signal Interface Module |
| Distributed Control System I/O | GE Industrial Electronics |
The GE IC660BBD025 is a Genius Block I/O Module designed for distributed industrial automation systems. It combines input and output functionality within a rugged field-mounted unit, allowing efficient communication between controllers and field devices across the Genius network.
Engineered for reliable operation in demanding environments, the IC660BBD025 offers fast signal processing, high isolation protection, and strong output capacity. It is widely used in manufacturing, process control, material handling, and machine automation applications requiring dependable remote I/O performance.
Distributed I/O Processing
Provides field-level input and output control for distributed automation systems using the GE Genius network.
Digital Signal Acquisition
Receives and processes input signals from sensors, switches, and other field devices.
Output Device Control
Controls actuators, relays, solenoids, and industrial loads through high-capacity output circuits.
High-Speed Signal Response
Supports typical input processing times of 1.4 ms and output turn-on delays of 0.5 ms for responsive control.
Network Communication Interface
Facilitates data exchange between field devices and central PLC or control systems.
Output Diagnostics Monitoring
Provides switch fault diagnostics to simplify troubleshooting and maintenance.
Electrical Isolation Protection
Offers 850V block-to-block isolation to improve system reliability and noise immunity.
Industrial Environment Operation
Designed to operate in temperatures from 0°C to 60°C and humidity levels from 5% to 95% non-condensing.
Compared with similar distributed I/O modules, the GE IC660BBD025 offers robust isolation, fast response times, and high output capacity, making it ideal for demanding industrial control applications.
High Output Capacity: Supports up to 16 Amps total block output current for controlling multiple field devices.
Fast Signal Processing: Delivers quick input processing and output response for real-time automation performance.
Strong Electrical Isolation: Provides 850V block-to-block isolation for enhanced system protection.
Built-In Diagnostics: Switch fault diagnostics help reduce maintenance time and improve system availability.
Reliable Industrial Design: Operates effectively in harsh industrial environments with wide temperature tolerance.
High Inrush Current Support: Handles up to 4 Amps inrush current for demanding load applications.
Efficient Distributed Control: Simplifies remote I/O deployment across Genius network architectures.
What is the maximum output current of GE IC660BBD025?
The GE IC660BBD025 supports up to 0.5 Amps per circuit and 16 Amps total block output current.
Does GE IC660BBD025 provide isolation protection?
Yes, the GE IC660BBD025 provides 850V block-to-block isolation to improve electrical protection and reliability.
What diagnostics are available in GE IC660BBD025?
The GE IC660BBD025 includes switch fault diagnostics for monitoring output circuit conditions.
What is the input processing speed of GE IC660BBD025?
The GE IC660BBD025 features a typical input processing time of 1.4 milliseconds.
Can GE IC660BBD025 operate in harsh industrial environments?
Yes, the GE IC660BBD025 operates in temperatures from 0°C to 60°C and supports humidity levels up to 95% non-condensing.
What types of devices can GE IC660BBD025 control?
The GE IC660BBD025 can interface with sensors, switches, relays, solenoids, actuators, and other industrial field devices.
