GE 90-30 Series PLC

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Product Parameters

Product Name	GE IC693ALG442 Analog Combination Module
Manufacturer	General Electric
Product Type	Analog Combination Module
Part Number	IC693ALG442
Weight	0.34 kg
Estimated shipping dimensions	3.5x13x13.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Inputs	4 differential analog inputs
Outputs	2 single-ended analog outputs
Input Ranges	0-20 mA, 4-20 mA, 4-20 mA Enhanced, 0-10 V, -10 to +10 V
Absolute Accuracy	±0.25% of full scale @ 25°C; ±0.5% over temperature range
Update Rate	3 ms
Power Consumption	95 mA from +5 VDC internal; 150 mA from +24 VDC external
External Supply Range	20 to 30 VDC (24 VDC typical)
Input Filter Response	38 Hz
Key Benefit	Solves the pain point of field signal integration by providing four configurable analog inputs and two outputs in a single module.

Introduction

The GE IC693ALG442 Analog Combination Module is a versatile industrial automation component designed by General Electric to simplify analog signal processing within PLC-based control systems. Combining four differential analog inputs and two single-ended analog outputs in a single compact module, it provides an efficient solution for applications requiring both monitoring and control of analog field devices. The module supports a wide range of input signal types, including 0–20 mA, 4–20 mA, enhanced 4–20 mA, 0–10 V, and -10 to +10 V, making it highly adaptable to diverse industrial environments.

The IC693ALG442 delivers precise measurement and control performance with an absolute accuracy of ±0.25% of full scale at 25°C and ±0.5% across the operating temperature range. Featuring a fast 3 ms update rate and a 38 Hz input filter response, the module ensures reliable real-time data acquisition and output control. Designed for integration into GE automation platforms, the IC693ALG442 helps reduce system complexity, save panel space, and improve overall control efficiency by consolidating analog input and output functionality into a single module.

Functions

Acquires analog signals from field devices through four differential analog input channels.
Provides two single-ended analog output channels for process control applications.
Supports multiple industry-standard current and voltage input ranges.
Converts field analog signals into digital data for PLC processing.
Delivers analog output signals to actuators, drives, and control equipment.
Enables simultaneous monitoring and control within a single module.
Provides fast signal updates with a 3 ms refresh rate.
Filters incoming signals through a 38 Hz input filter for stable measurements.
Supports integration of sensors, transmitters, valves, and other analog devices.
Helps reduce hardware requirements by combining input and output functions in one module.

Features

Analog combination module with integrated input and output functionality
Four differential analog input channels for accurate signal acquisition
Two single-ended analog output channels for process control applications
Supports multiple analog signal types, including current and voltage inputs
Compatible with 0–20 mA, 4–20 mA, and enhanced 4–20 mA current signals
Supports 0–10 V and -10 V to +10 V voltage input ranges
High accuracy of ±0.25% of full scale at 25°C
Maintains ±0.5% accuracy across the specified temperature range
Fast 3 ms update rate for responsive data processing
38 Hz input filter response for stable and noise-resistant signal conditioning
Simultaneous monitoring and control capability within a single module
Requires only 95 mA from the internal +5 VDC power supply
Uses 150 mA from an external +24 VDC power source
Operates with an external supply voltage range of 20–30 VDC
Supports integration of sensors, transmitters, actuators, and control devices
Compact design helps optimize PLC rack and control cabinet space
Lightweight construction simplifies installation and maintenance
Designed for continuous operation in industrial automation environments
Reduces system complexity by combining analog input and output functions
Suitable for process control, manufacturing, utility, and infrastructure applications.

Advantage

Compared with other analog combination modules that offer similar input and output functionality, the IC693ALG442 provides greater integration efficiency, flexible signal compatibility, and reliable performance in a compact design, making it an effective solution for modern industrial control systems.

Integrates four analog inputs and two analog outputs in a single module, reducing hardware requirements.
Supports multiple current and voltage signal ranges, increasing application flexibility.
Delivers high measurement accuracy for improved process reliability and control precision.
Features a fast 3 ms update rate for responsive monitoring and process adjustments.
Reduces panel space requirements compared to separate analog input and output modules.
Simplifies wiring and installation, lowering engineering and maintenance efforts.
Enables simultaneous signal acquisition and output control within one platform.
Compatible with a wide range of industrial sensors, transmitters, and actuators.
Maintains stable performance under demanding industrial operating conditions.
Offers a cost-effective solution by minimizing module count and overall system complexity.

The IC693ALG442 combines versatility, accuracy, and space-saving design, providing a practical advantage over many comparable analog combination modules that require additional hardware to achieve the same level of functionality.

FAQ

Q: How many input and output channels does the IC693ALG442 support?
A: The IC693ALG442 supports four differential analog input channels and two single-ended analog output channels.

Q: What signal ranges are supported by the IC693ALG442?
A: The IC693ALG442 supports 0–20 mA, 4–20 mA, enhanced 4–20 mA, 0–10 V, and -10 V to +10 V input ranges.

Q: What is the accuracy specification of the IC693ALG442?
A: The IC693ALG442 provides an accuracy of ±0.25% of full scale at 25°C and ±0.5% across the specified operating temperature range.

Q: What is the update rate of the IC693ALG442?
A: The IC693ALG442 features a fast 3 ms update rate, enabling efficient real-time process monitoring and control.

Q: What power requirements does the IC693ALG442 have?
A: The IC693ALG442 consumes 95 mA from the internal +5 VDC supply and requires 150 mA from an external +24 VDC power source.

Q: What is the external supply voltage range for the IC693ALG442?
A: The IC693ALG442 operates with an external power supply ranging from 20 to 30 VDC, with 24 VDC being the typical operating voltage.
