Product Name: Thermocouple Input Module
Brand Name: General Electric
Model Number: IS220PTCCH1A
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | GE IS220PTCCH1A Thermocouple Input Module |
| Manufacturer | GE |
| Product Type | Thermocouple Input Module |
| Part Number | IS220PTCCH1A |
| Weight | 0.38kg |
| Estimated shipping dimensions | 12.8x8.2x6cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Manufacturer | General Electric |
| Number of Channels | 12 |
| Span | -8 mV to +45 mV |
| A/D Converter | 16-bit |
| Common Mode Voltage | +5 Volts |
| Normal Mode Rejection | 250mV |
| Microprocessor | AMD-K6 300 MHz |
| Operating temperature | -30 to 65 °C |
The GE IS220PTCCH1A is a high-performance Thermocouple Input Module designed for industrial process monitoring and control applications. Manufactured by General Electric, this module is engineered to accurately acquire and process thermocouple signals, enabling reliable temperature measurement in critical industrial environments. As part of GE's advanced control system architecture, the IS220PTCCH1A provides precise data acquisition capabilities that support enhanced process efficiency and operational safety.
Featuring 12 thermocouple input channels, a 16-bit A/D converter, and a powerful AMD-K6 300 MHz microprocessor, the IS220PTCCH1A delivers accurate and responsive temperature signal processing. The module supports an input span of -8 mV to +45 mV and is designed to operate in demanding industrial conditions with an operating temperature range of -30°C to 65°C. Its robust construction and reliable performance make it suitable for power generation, oil and gas, manufacturing, and other process automation applications.
Compared with other thermocouple input modules with similar functions, the IS220PTCCH1A offers higher measurement accuracy, greater channel capacity, strong noise immunity, and reliable performance in demanding industrial environments.
High Measurement Accuracy
The IS220PTCCH1A utilizes a 16-bit A/D converter to provide precise signal conversion and temperature measurement. Compared with lower-resolution modules, it delivers more accurate process data, helping operators achieve tighter process control and improved operational efficiency.
Multi-Channel Monitoring Capability
With support for 12 thermocouple input channels, the IS220PTCCH1A can monitor multiple temperature points simultaneously. This reduces the need for additional hardware and simplifies system design when compared with modules that offer fewer input channels.
Reliable Operation in Harsh Industrial Environments
The IS220PTCCH1A is designed to operate within a wide temperature range of -30°C to 65°C, enabling dependable performance in challenging industrial conditions. This environmental durability gives it an advantage over modules with narrower operating temperature specifications.
Advanced Processing Performance
Equipped with an AMD-K6 300 MHz microprocessor, the IS220PTCCH1A provides fast data processing and responsive system communication. This allows for more efficient temperature monitoring and quicker response to changing process conditions compared with less powerful alternatives.
Enhanced Noise Immunity
The IS220PTCCH1A incorporates common mode voltage tolerance and 250 mV normal mode rejection to help minimize the effects of electrical interference. This contributes to more stable and reliable temperature measurements, particularly in electrically noisy industrial environments.
Trusted GE Quality and System Compatibility
As a genuine General Electric control system component, the IS220PTCCH1A offers proven reliability, long-term performance, and seamless integration with GE automation platforms. This compatibility reduces commissioning complexity and supports easier maintenance throughout the product lifecycle.
What is the primary purpose of the IS220PTCCH1A?
The IS220PTCCH1A is a thermocouple input module designed to acquire, process, and transmit temperature measurement data from thermocouple sensors to industrial control systems for monitoring and process control applications.
How many thermocouple channels does the IS220PTCCH1A support?
The IS220PTCCH1A supports up to 12 thermocouple input channels, allowing multiple temperature measurement points to be monitored simultaneously within a single module.
What input signal range is supported by the IS220PTCCH1A?
The IS220PTCCH1A supports an input span ranging from -8 mV to +45 mV, making it suitable for processing signals from a wide variety of thermocouple types used in industrial applications.
What type of analog-to-digital conversion does the IS220PTCCH1A use?
The IS220PTCCH1A utilizes a 16-bit A/D converter, providing high-resolution signal conversion for accurate temperature monitoring and process control.
What operating temperature range is supported by the IS220PTCCH1A?
The IS220PTCCH1A is designed to operate reliably in ambient temperatures ranging from -30°C to 65°C, making it suitable for both standard and harsh industrial environments.
