Product Name: TMR DIN Rail Assembly Board
Brand Name: GE
Model Number:IS230TAISH2C/IS200TBAIS1CED
Country of Origin:USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
General Electric |
Model Number: |
IS230TAISH2C/IS200TBAIS1CED |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
IS230TAISH2C |
IS200TBAIS1CED |
|
Manufacturer |
General Electric (GE) |
General Electric (GE) |
|
Product Series |
Mark VIe Speedtronic™ |
Mark VI / Mark VIe Speedtronic™ |
|
Product Type |
TMR DIN Rail Assembly Board |
Analog I/O Terminal Board |
|
Terminal Capacity |
||
|
Redundancy Support |
Triple Modular Redundancy (TMR) |
|
|
Input Signal Range |
||
|
Input Accuracy |
— |
|
|
Power Supply |
||
|
Output Voltage |
— |
|
|
Operating Temperature |
||
|
Storage Temperature |
— |
|
|
Mounting |
35 mm DIN rail |
|
|
Dimensions (W×H×D) |
||
|
Weight |
||
|
Connectors |
— |
|
|
Certifications |
UL 508, CE |
|
|
Country of Origin |
USA |
The GE IS230TAISH2C is a TMR DIN Rail Assembly Board designed for the Mark VIe control system, providing fault tolerance and high availability for critical applications. When paired with the GE IS200TBAIS1CED Analog I/O Terminal Board, the assembly provides a robust interface for field devices, supporting up to 48 terminals and accepting 0–20 mA, 4–20 mA, 0–5 V, and 0–10 V analog inputs. Both the IS230TAISH2C and IS200TBAIS1CED are built for harsh industrial environments with wide temperature ranges and hazardous location certifications, making them ideal for mission-critical turbine and power generation control systems.
Gas and steam turbine control – provides fault‑tolerant I/O for speed, temperature, and pressure monitoring
Power generation – critical control and monitoring in combined‑cycle and nuclear plants
Industrial automation – high‑reliability discrete and analog I/O for manufacturing processes
Hazardous location installations – Class I Division 2 and Zone 2 certified environments
Safety Instrumented Systems (SIS) – supports TMR configurations for SIL‑rated applications
Triple Modular Redundancy (TMR) – ensures fault tolerance and continuous operation in critical systems
48 terminal capacity – secure, high‑density connections for field devices and sensors
Wide analog input support – accepts 0–20 mA, 4–20 mA, 0–5 V, and 0–10 V signals
±0.1% input accuracy – precise signal measurement for critical control loops
Dual compatibility – works with both 2‑wire and 4‑wire analog transmitters
Hazardous location certified – UL E207685, Class I Division 2, Groups A‑D, and Zone 2
Wide operating temperature – –40°C to +70°C for harsh environments
Conformal coating – protects against moisture, dust, and mechanical impacts
Provides fault‑tolerant I/O interface – distributes analog signals to R, S, and T I/O packs in TMR configurations
Acquires and conditions analog signals – converts field sensor signals (current/voltage) for the Mark VIe controller
Supports redundant network communication – integrates with IONet for synchronized controller operation
Performs continuous diagnostics – monitors input signal integrity and reports faults
Interfaces with multiple transmitter types – supports 2‑wire, 3‑wire, 4‑wire, and externally powered transmitters
Q1: What is the IS230TAISH2C used for?
A1: The IS230TAISH2C is a TMR DIN Rail Assembly Board for the Mark VIe control system, providing fault‑tolerant I/O connectivity for critical turbine and industrial automation applications.
Q2: What analog signals does the IS230TAISH2C support?
A2: The IS230TAISH2C supports 0–20 mA, 4–20 mA, 0–5 V, and 0–10 V analog input signals.
Q3: Is the IS200TBAIS1CED compatible with both Mark VI and Mark VIe systems?
A3: Yes. The IS200TBAIS1CED is compatible with both Mark VI and Mark VIe series control systems.
Q4: What redundancy options are supported?
A4: The assembly supports Simplex (single controller), Dual Controller, and TMR (Triple Modular Redundancy) configurations.
Q5: What are the hazardous location certifications for the IS230TAISH2C?
A5: The IS230TAISH2C is certified for Class I, Division 2, Groups A, B, C, D and Class I, Zone 2, with UL E207685 listing.
