General Electric DS3800NMEC1K1K Motor Exciter Control Board

General Electric DS3800NMEC1K1K Motor Exciter Control Board

Product Name: Motor Exciter Control Board

Brand Name: General Electric

Model Number: DS3800NMEC1K1K

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Overview
Specifications
Commercial Terms
Contact Us
Advantages
FAQ
Why Choose Us
Major Business
Recommended Products

Overview

The General Electric DS3800NMEC1K1K Motor Exciter Control Board is a high-performance motor exciter control board designed for GE Mark IV turbine control systems. It features 24–48 VDC input voltage, 5 A continuous output current, ±0.5% voltage regulation accuracy, response time below 10 ms, and six external connection interfaces for dependable excitation control and system integration. Designed to provide precise excitation management and stable generator voltage regulation, the board enhances operational reliability, supports coordinated control functions, and improves overall power system performance. Its compatibility with GE Mark IV platforms makes it an ideal solution for gas turbines, steam turbines, generator excitation systems, and industrial power generation applications.

Specifications

Product Name	General Electric DS3800NMEC1K1K Motor Exciter Control Board
Manufacturer	General Electric
Product Type	Motor Exciter Control Board
Part Number	DS3800NMEC1K1K
Place of shipment	Xiamen, China
Country of origin	USA
Input Voltage	24 – 48 VDC
Output Current	Maximum 5A continuous current
Voltage Regulation Accuracy	±0.5%
Response Time	< 10 ms
Number of Chips	35 ICs (including ROM firmware)
Adjustment Element	1 0-100 field-adjustable knob
Signal Components	1 crystal oscillator, 10 transistors, approximately 100 resistors
Connection Interface	6 male connectors
Operating Temperature	0°C to 60°C
Operating Humidity	5% – 95% RH (non-condensing)

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Advantages

Accurate Excitation Control
Provides precise excitation voltage regulation with fast response characteristics, helping maintain stable generator performance under varying load conditions.

Fast Dynamic System Response
Responds rapidly to changes in operating conditions, improving system stability during startup, synchronization, normal operation, and shutdown sequences.

Reliable Industrial Hardware Design
Incorporates high-quality integrated circuits, signal-conditioning components, and firmware architecture to ensure dependable long-term performance in demanding industrial environments.

Flexible System Integration
Features multiple connection interfaces for seamless integration with GE Mark IV control systems, automatic voltage regulators, and excitation control architectures.

Stable Power Generation Performance
Supports continuous excitation management while improving voltage stability, operational reliability, and coordinated protection for generator control systems.

Ideal for Turbine Control Applications
Well suited for gas turbines, steam turbines, generator excitation systems, power generation facilities, and other industrial applications requiring reliable excitation control.

FAQ

Q1: What is the DS3800NMEC1K1K used for?
A: The DS3800NMEC1K1K is a motor exciter control board used to regulate generator excitation and maintain stable voltage output within GE Mark IV turbine control systems.

Q2: Which control system is the DS3800NMEC1K1K compatible with?
A: The DS3800NMEC1K1K is designed for compatibility with GE Mark IV gas turbine and steam turbine control systems.

Q3: What are the main functions of the DS3800NMEC1K1K?
A: The DS3800NMEC1K1K provides excitation regulation, voltage stabilization, coordinated control, and support for reliable generator operation during various operating conditions.

Q4: Does the DS3800NMEC1K1K support fast response control?
A: Yes. The DS3800NMEC1K1K delivers rapid response performance, helping maintain stable excitation control and efficient adjustment to changing load conditions.

Q5: Can the DS3800NMEC1K1K be used in redundant excitation systems?
A: Yes. The DS3800NMEC1K1K supports integration with redundant excitation control arrangements, enhancing system availability and operational reliability.

Q6: Which industrial applications are suitable for the DS3800NMEC1K1K?
A: The DS3800NMEC1K1K is widely used in gas turbines, steam turbines, generator excitation systems, power generation plants, and other industrial applications requiring dependable excitation control and voltage regulation.
