Product Name:ADVANCED COMMUNICATION BOARD
Brand Name:Honeywell
Model Number:51304685-150
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
51304685-150 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Details |
|
Model |
51304685-150 |
|
System Compatibility |
Honeywell TDC 3000X |
|
Module Type |
I/O / Interface Module |
|
Installation Format |
5-Slot / 10-Slot Rack System |
|
Communication Interface |
LCN / System Bus |
|
Power Requirement |
5V / 12V DC (system dependent) |
|
Operating Temperature |
0°C to 60°C |
|
Storage Temperature |
-40°C to 85°C |
|
Humidity |
5% – 95% non-condensing |
|
Dimension |
2.9x31.9x27.9cm |
|
Weight |
0.92kg |
The 51304685-150 is an industrial-grade module designed for integration within Honeywell TDC 3000X distributed control systems, providing reliable signal processing and system communication performance. It is engineered to support stable operation in complex automation environments where high system availability and precise data handling are essential.
Built as part of a modular and interchangeable architecture, 51304685-150 works seamlessly with related Honeywell system components such as 51304690-100 and other compatible I/O and interface modules. Its flexible design allows efficient configuration within Five- and Ten-Slot module frameworks, supporting diverse process control requirements.
With robust construction and optimized board-level integration, the module ensures dependable performance for long-term industrial operation. It is widely applied in control network expansion, system interfacing, and distributed automation tasks across demanding industrial environments.
Q1: What system is 51304685-150 compatible with?
A1: It is designed for the Honeywell TDC 3000X control system architecture.
Q2: Can 51304685-150 be used with other modules?
A2: Yes, it works with compatible Honeywell interface and I/O modules in the same rack system.
Q3: What is the main function of this module?
A3: It provides stable signal processing and system communication in industrial automation environments.
Q4: Is 51304685-150 suitable for harsh environments?
A4: Yes, it is designed for reliable performance in industrial conditions with electrical noise and temperature variation.
Q5: How is the module installed?
A5: It is mounted in standard Five-Slot or Ten-Slot rack systems within the control cabinet.
