Honeywell 8C-SHEDA1 51307186-175 Series 8 Header Board Original new

Honeywell 8C-SHEDA1 51307186-175 Series 8 Header Board Original new

Product Name:Series 8 Header Board

Brand Name:Honeywell

Model Number:8C-SHEDA1 51307186-175

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell 8c sheda1 51307186 175 series 8 header board original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	8C-SHEDA1 51307186-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Details
Product Model	8C-SHEDA1 51307186-175
Product Type	Series 8 Header Board
System Compatibility	Honeywell PlantCruise / Experion PKS
Power Input	24 VDC
Power Output	24 VDC
Communication	I/O Link
Power Connectors	3 Ports
Combo Cable Ports	4 pairs (6-pin)
I/O Link Extension	2 pairs (3-pin)
Cable Type	Combo Power + IOLINK Cable
Redundancy Support	Yes
Mounting Type	Cabinet Mounted
Operating Temperature	0 to 60°C
Dimensions	66x5x4cm
Weight	0.34kg
Installation Type	DIN / Panel Mount

Description

8C-SHEDA1 51307186-175 is a Series 8 Header Board designed for Honeywell PlantCruise by Experion and C300 I/O systems. It is responsible for distributing 24 VDC power and I/O Link communication signals across cabinet-mounted I/O modules, ensuring stable system operation and efficient communication between controllers and field devices. It is commonly used with Series 8 I/O architecture including modules such as 8C-TAID61 and related IOTA units.

The modular design of 8C-SHEDA1 supports multiple I/O columns within a control cabinet, allowing flexible system expansion and simplified wiring configuration. It also enables daisy-chained combo cable connections, ensuring continuous operation even when individual modules are disconnected.

With redundant power and communication capability, 8C-SHEDA1 51307186-175 improves system reliability in industrial automation environments. It is widely applied in large-scale distributed control systems requiring stable power management and robust I/O communication.

Applications

Power plants: Used for cabinet power distribution, turbine monitoring systems, and relay protection.
Substations: Enable I/O communication for switchyard control and protection systems.
Chemical plants: Support distributed control systems and safe signal transmission.
Steel mills: Operate reliably in high EMI and high-temperature environments.
Oil & gas facilities: Provide stable power and communication for critical automation systems.
Machinery manufacturing plants: Used in automated production lines and robotic control systems.
Water treatment plants: Support process monitoring and pump control automation.

Features

Distributes 24 VDC power across I/O modules
Supports I/O Link communication architecture
Redundant power and communication design
Daisy-chain cable connection capability
Supports multi-column cabinet expansion
Compact industrial-grade construction
High reliability for continuous operation
Compatible with Honeywell Series 8 systems

Functions

Distributes power to I/O modules and IOTAs
Enables I/O Link communication between system components
Supports redundant cabinet-level architecture
Simplifies wiring and system integration
Enhances control system stability
Reduces installation complexity and maintenance time

FAQ

Q1: What is the main function of 8C-SHEDA1 51307186-175?
A1: It distributes 24 VDC power and I/O Link communication to Series 8 I/O modules in Honeywell control systems.

Q2: Does 8C-SHEDA1 support redundancy?
A2: Yes, it supports redundant power distribution and communication pathways.

Q3: Which system is compatible with this header board?
A3: It is compatible with Honeywell PlantCruise by Experion and Series 8 I/O architecture.

Q4: Can it support multiple I/O modules?
A4: Yes, it can support multiple I/O columns through its multi-connector design.

Q5: What type of cable is used with 8C-SHEDA1?
A5: It uses a combination power and I/O Link daisy-chain cable system.
