Product Name:analog input module
Brand Name:Honeywell
Model Number:8C-TAIDA1 51307131-175
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
8C-TAIDA1 51307131-175 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Details |
|
Product Model |
8C-TAIDA1 51307131-175 |
|
Product Type |
Analog Input IOTA (Non-redundant) |
|
Compatible Module |
8C-PAIH54 / 8C-PAIHA1 / 8C-PAINA1 |
|
Input Type |
Voltage / Current (4–20 mA) |
|
Input Channels |
16 Channels |
|
Signal Mode |
Single-ended / Differential |
|
IOTA Size |
9 in (228 mm) |
|
Power Supply |
24 VDC |
|
Mounting Type |
Cabinet / Vertical Mount |
|
Coating Type |
Conformal Coated |
|
A/D Resolution |
16-bit |
|
Scan Rate |
50 ms |
|
Operating Temperature |
Industrial environment rated |
|
Dimensions |
22x12x8cm |
|
Weight |
0.32kg |
|
Protection |
Short-circuit protected inputs |
8C-TAIDA1 51307131-175 is a Series 8 Analog Input IOTA module engineered for Honeywell PlantCruise by Experion and C300 control systems. It provides a reliable platform for high-level analog signal termination and processing, ensuring stable data acquisition from field transmitters in demanding industrial automation environments. Designed to work seamlessly with modules such as 8C-PAIH54, it supports both single-ended and differential input configurations for flexible system integration.
Built with a compact 9-inch architecture, 8C-TAIDA1 optimizes cabinet space while improving heat dissipation and wiring efficiency. Its rugged design ensures accurate signal handling even under electrically noisy and high-vibration conditions commonly found in industrial plants.
With conformal-coated protection, 8C-TAIDA1 51307131-175 enhances resistance against moisture, dust, and chemical exposure. It is widely used in distributed control systems (DCS) for power generation, oil & gas, petrochemical, and heavy manufacturing applications where long-term reliability is essential.
Q1: What is the function of 8C-TAIDA1 51307131-175?
A1: It is an Analog Input IOTA used to terminate and process field analog signals in Honeywell Series 8 control systems.
Q2: Which modules are compatible with 8C-TAIDA1?
A2: It works with 8C-PAIH54, 8C-PAIHA1, and 8C-PAINA1 analog input modules.
Q3: Does 8C-TAIDA1 support redundancy?
A3: No, this model is a non-redundant IOTA designed for standard analog input applications.
Q4: What types of signals does it support?
A4: It supports 4–20 mA current signals and voltage inputs in both single-ended and differential modes.
Q5: Is 8C-TAIDA1 51307131-175 suitable for harsh environments?
A5: Yes, its conformal-coated design ensures protection against dust, moisture, and industrial contaminants.
| Number (I/O Module Coated) | Description |
|---|---|
| 8C-PAIH54 | High-level AI HART, Differential |
| 8C-TAIDA1 | AI IOTA |
| 8C-TAIDB1 | AI IOTA Redundant |
| 8C-PAIHA1 | High-level AI HART, Single-ended |
| 8C-PAINA1 | High-level AI w/o HART, Single-ended |
| 8C-TAIXA1 | AI IOTA |
| 8C-TAIXB1 | AI IOTA Redundant |
| 8C-PAIMA1 | Low-level AI – RTD & TC |
| 8C-TAIMA1 | Low-level AI IOTA |
| 8C-PAOHA1 | Analog Output HART |
| 8C-PAONA1 | Analog Output w/o HART |
| 8C-TAOXA1 | AO IOTA |
| 8C-TAOXB1 | AO IOTA Redundant |
| 8C-PDILA1 | Digital Input 24V |
| 8C-PDISA1 | Digital Input Sequence of Events |
| 8C-PDIPA1 | Digital Input 24V Pulse Accumulation |
| 8C-TDILA1 | DI 24V IOTA |
| 8C-TDILB1 | DI 24V IOTA Redundant |
| 8C-PDODA1 | DO 24V Bussed Out |
| 8C-TDODA1 | DO 24V IOTA |
| 8C-TDODB1 | DO 24V IOTA Redundant |
| 8C-SDOX01 | DO Relay Extension |
