Honeywell CC-PDIL01 51405040-176 Digital Input Module

Honeywell CC-PDIL01 51405040-176 Digital Input Module

Product Name: Digital Input Module

Brand Name: Honeywell

Model Number: CC-PDIL01 51405040-176

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

honeywell cc pdil01 51405040 176 digital input module-1

Overview
Specifications
Contact Us
Overview
Functions
Why Choose Us
Major Business
After-sales Service
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Product Name	Honeywell CC-PDIL01 51405040-176 Digital Input Module
Manufacturer	Honeywell
Product Type	Digital Input Module
Part Number	CC-PDIL01 51405040-176
Weight	0.36kg
Estimated shipping dimensions	5.5x16x14.5cm
Place of shipment	Xiamen, China
Country of origin	USA
Input Channels	32
Nominal Voltage	24V DC
DI Power Voltage Range	18 to 30 VDC
ON Sense Threshold	13V DC (min) or 3 mA (min)
OFF Sense Threshold	5V DC (max) or 1.2 mA (max)
Input Impedance	4.2 kΩ
Galvanic Isolation	1500 VAC RMS or ±1500 VDC
Isolation Technique	Optical (in IOM)
Absolute Delay	5 ms ±20%
Field Resistance (ON)	≤300Ω @ 15 VDC
Field Resistance (OFF)	≥30kΩ @ 30 VDC

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Overview

The Honeywell CC-PDIL01 51405040-176 Digital Input Module is a high-density 32-channel digital input module designed for Honeywell industrial control and distributed control systems. It features 24 VDC nominal input voltage, 32 isolated digital input channels, 1500 VAC RMS galvanic isolation, and optical isolation technology for reliable signal acquisition and electrical protection. Designed to accurately monitor field device status and transmit digital signals to the control system, the module enhances system reliability, simplifies field wiring, and supports continuous industrial operation. It is an ideal solution for process automation, power generation, oil and gas, chemical processing, water treatment, and manufacturing applications.

Functions

Digital Signal Acquisition
Collects ON/OFF status signals from field devices such as limit switches, push buttons, relays, proximity sensors, and auxiliary contacts for real-time process monitoring.

32-Channel Input Processing
Provides 32 independent digital input channels, enabling high-density signal acquisition while reducing cabinet space and overall system hardware requirements.

Optical Signal Isolation
Utilizes optical isolation technology to electrically separate field signals from the control system, minimizing the effects of electrical noise and improving operational reliability.

Field Device Status Monitoring
Continuously monitors the operating status of connected equipment and transmits digital input data to the controller for process supervision and automation.

Industrial Electrical Protection
Offers 1500 VAC RMS galvanic isolation to protect the automation system from voltage transients, electrical interference, and potential ground loop issues.

Seamless DCS Integration
Integrates directly with Honeywell distributed control systems, providing dependable digital input acquisition for process automation, power plants, chemical facilities, water treatment systems, and other critical industrial applications.
