Honeywell CC-TAIN01 51306513-175 Analog Input Module In stock, China Honeywell CC-TAIN01 51306513-175 Analog Input Module In stock Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	CC-TAIN01 51306513-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	CC-TAIN01 51306513-175
Product Type	Analog Input IOTA Module
Compatible IOM	CC-PAIN01
Input Type	4–20 mA Current Input
Input Channels	16 Single-Ended Channels
A/D Resolution	16-bit
Input Scan Rate	50 ms
Common Mode Rejection	70 dB
Normal Mode Rejection	20 dB
Maximum Input Voltage	±30 V
Crosstalk	-60 dB
Accuracy	±0.075% Full Scale
Operating Architecture	Honeywell Experion Series C
Mounting Size	6-inch (152 mm) IOTA
Wiring Support	Up to 12 AWG / 2.5 mm² stranded wire
Power Feature	Non-incendive field power
Redundancy Support	Non-redundant
Approximate Weight	Approx. 0.6 kg
Dimensions	152 mm × 130 mm × 90 mm (approx.)

Description

Honeywell CC-TAIN01 51306513-175 is a high-performance non-redundant analog input IOTA designed for the Experion® Series C control platform. The module supports reliable 4–20 mA signal acquisition from industrial transmitters and field sensing devices while simplifying cabinet wiring and system integration. Its compact 6-inch design helps reduce panel space requirements in modern DCS environments.

Engineered for demanding industrial automation systems, CC-TAIN01 works together with CC-PAIN01 analog input modules to deliver stable process monitoring, fast loop scanning, and advanced diagnostic functionality. The unit features integrated non-incendive field power conditioning, eliminating the need for additional marshalling hardware and improving installation efficiency.

As part of the Honeywell Series C architecture, CC-TAIN01, CC-TAIN11, and related Series C I/O assemblies provide scalable and maintainable process control solutions for power generation, petrochemical processing, manufacturing automation, and critical infrastructure applications requiring dependable analog signal handling and high system availability.

Applications

Power plants: Used for turbine process monitoring, analog signal acquisition, and DCS process control systems.
Substations: Supports reliable current signal collection for automation and monitoring applications.
Chemical plants: Integrates with distributed control systems for stable process instrumentation management.
Steel mills: Performs continuous analog monitoring in high-temperature and electrically noisy environments.
Machinery manufacturing plants: Applied in automated production systems, packaging equipment, and industrial process lines.
Oil & gas facilities: Handles transmitter signal inputs for pressure, temperature, and flow monitoring.
Water treatment systems: Provides accurate analog data collection for pumps and process instrumentation.

Features

Extensive self-diagnostic capability
Supports 16 analog input channels
Fast 50 ms loop scan performance
Integrated non-incendive field power
Compact 6-inch Series C IOTA design
Simplified cabinet installation structure
High noise immunity and stable signal acquisition
Compatible with Honeywell Experion PKS systems
Reduced external marshalling requirements
Supports industrial-grade process reliability

Functions

Receives 4–20 mA transmitter signals
Interfaces field devices with DCS controllers
Converts analog process signals for monitoring
Supplies protected field loop power
Supports continuous process measurement
Enhances industrial automation stability
Improves maintenance and troubleshooting efficiency
Provides secure signal conditioning for hazardous areas

FAQ

Q1: What is the main function of the CC-TAIN01 51306513-175?
A1: It is a Honeywell analog input IOTA used for acquiring 4–20 mA process signals in Experion Series C systems.

Q2: How many channels does the module support?
A2: The module supports 16 single-ended analog input channels.

Q3: Is the CC-TAIN01 compatible with HART communication?
A3: No, this model is designed for standard analog input applications without HART functionality.

Q4: Which module works together with CC-TAIN01?
A4: It is commonly paired with the CC-PAIN01 high-level analog input module.

Q5: Does the module support hazardous area applications?
A5: Yes, it provides non-incendive field power suitable for Division 2 industrial environments.

Spares

Number	Description
CC-PAIN01	High-Level Analog Input Module
CC-TAIN11	Redundant Analog Input IOTA
CC-PAIH01	Analog Input Module with HART
CC-PAIH02	High-Level Analog Input with HART
CC-TAIX01	Analog Input IOTA
CC-TAIX11	Redundant Analog Input IOTA
CC-PAIH51	High-Level Analog Input HART Module
CC-TAIX51	Non-Redundant AI HART IOTA
CC-TAIX61	Redundant AI HART IOTA
CC-PUIO31	Universal Input Output Module
