Honeywell CC-TDIL11 51308388-175 Digital Input IOTA 24V Ready For Ship, China Honeywell CC-TDIL11 51308388-175 Digital Input IOTA 24V Ready For Ship Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	CC-TDIL11 51308388-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Details
Model	CC-TDIL11 51308388-175
Type	24VDC Digital Input Redundant IOTA
Input Channels	32 Channels
IOTA Type	Redundant 12-inch
Isolation	1000 VAC RMS
Power Range	18–30 VDC
Input Impedance	4.2 KΩ
Response Time	~5 ms
Dimension	29.4x12x6.5cm
Weight	0.46kg
Wiring Type	Field terminal block
Mounting	DIN / Cabinet mount

Description

CC-TDIL11 51308388-175 is a redundant 24VDC digital input IOTA designed for reliable discrete signal acquisition in Honeywell Series C control systems. It supports stable field signal processing with enhanced diagnostic capability, ensuring high data integrity in industrial automation environments.

The module is compatible with multiple Series C input modules including CC-PDIL01, CC-PDIL51, and CC-PDIS01, providing flexible integration for standard input and sequence-of-events applications. Its redundant IOTA architecture improves system availability and minimizes downtime in critical processes.

Built with optical isolation and galvanic separation, CC-TDIL11 51308388-175 delivers strong electrical protection, open-wire detection support, and simplified field wiring. It is widely applied in power, process, and heavy industrial automation systems requiring dependable 24VDC signal handling.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enables bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Supports process automation and intrinsically safe signal monitoring.
Steel mills: Ensures stable logic control under high temperature and EMI conditions.
Machinery manufacturing plants: Used in automated production lines, robotic systems, and packaging control.

Features

Redundant IOTA architecture for high system availability
32-channel 24VDC digital input support
Optical isolation for electrical noise protection
Built-in open-wire detection capability
Supports internal/external field power selection
Compact 12-inch design for cabinet optimization
Plug-in IOM structure for easy maintenance

Functions

Accepts discrete 24VDC input signals
Provides real-time signal acquisition to control system
Detects wiring faults and abnormal field conditions
Supports redundancy switchover operation
Ensures signal isolation between field and controller
Enables stable data transmission to DCS/PLC systems
Improves system reliability in harsh environments

FAQ

Q1: What is CC-TDIL11 51308388-175 used for?
A1: It is used for collecting 24VDC digital input signals in redundant industrial control systems.

Q2: Does CC-TDIL11 support redundancy?
A2: Yes, it is designed with a redundant IOTA structure for higher system reliability.

Q3: How many input channels does it support?
A3: It supports up to 32 discrete digital input channels.

Q4: What protection features are included?
A4: It includes optical isolation and open-wire detection for enhanced safety.

Q5: Where is CC-TDIL11 commonly applied?
A5: It is widely used in power plants, substations, and industrial automation systems.
