Honeywell FC-RUSIO-3224 Universal Safe IO device (32 channels, 24 V DC) Original new, China Honeywell FC-RUSIO-3224 Universal Safe IO device (32 channels, 24 V DC) Original new Manufacturers, Suppliers, Factory

Overview

Brand Name:	Honeywell
Model Number:	FC-RUSIO-3224
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model Number	FC-RUSIO-3224
Product Type	Universal Safe IO Module
IO Channels	32 Universal Configurable Channels
Input/Output Types	DI, DO, AI, AO
Operating Voltage	24 V DC
Analog Input Range	0–20 mA / 4–20 mA
Analog Output Range	0–20 mA / 4–20 mA
Digital Output Current	Up to 0.5 A per channel
Communication	Dual 100 Mbaud Ethernet
Safety Level	SIL 3 compliant
A/D Conversion	16-bit
D/A Conversion	12-bit
Diagnostic Features	Self-test, watchdog, line monitoring
Mounting Method	IOTA mounting
Dimensions	7.3x16x16.4cm
Weight	0.62kg
Approvals	CE, TÜV, UL, CSA, FM

Description

FC-RUSIO-3224is a high-performance universal safety I/O module developed for advanced industrial safety systems and critical process automation applications. Designed for SIL 3 environments, the module delivers 32 configurable safe I/O channels capable of handling digital inputs, digital outputs, analog inputs, and analog outputs within a single compact platform.FS-RUSIO-3224andFC-RUSIO-3224provide flexible integration for modern Safety Manager architectures.

The module supports 24 V DC field signals and uses dual 100 Mbaud Ethernet communication links for reliable data exchange with the Safety Manager Controller. Its redundant processor architecture and dedicated diagnostic functions help improve operational reliability in demanding industrial environments. The integrated watchdog circuitry, temperature monitoring, and configurable ESD functionality further enhance system protection and availability.

With its modular Series C housing design,FC-RUSIO-3224is widely used in power generation, petrochemical plants, emergency shutdown systems, and high-availability process control networks. The module enables simplified field wiring, fast configuration through Safety Builder, and dependable long-term operation in mission-critical automation systems.

Applications

Power plants: Used for turbine control systems, emergency shutdown logic, and generator protection monitoring.
Substations: Supports relay protection, switchgear monitoring, and redundant signal acquisition systems.
Chemical plants: Provides safe analog and digital process control for hazardous production environments.
Oil & gas facilities: Applied in ESD systems, fire & gas systems, and critical process safety loops.
Steel mills: Performs reliable automation control under high electromagnetic interference conditions.
Water treatment plants: Monitors pumps, valves, and instrumentation for continuous process safety.
Machinery manufacturing plants: Integrates robotic systems, automated production lines, and industrial control networks.

Features

32 configurable universal safety IO channels
Supports DI, DO, AI, and AO functions
SIL 3 compliant safety architecture
Dual Ethernet communication ports
Integrated watchdog and self-diagnostic functions
Redundant processor communication support
Configurable ESD safety input function
Real-time SOE timestamp recording
Compact Honeywell Series C module design
Supports line-monitored digital IO applications

Functions

Collects and processes field input signals
Executes hardware diagnostic testing automatically
Exchanges real-time data with Safety Manager Controller
Controls digital and analog field devices safely
Supports emergency shutdown operations
Detects wiring faults and channel abnormalities
Provides analog signal monitoring and output control
Enables redundant safety communication architecture
Supports online firmware and configuration updates

FAQ

Q1:What is the main function of theFC-RUSIO-3224module?
A1:It provides configurable universal safe IO functions for SIL 3 industrial safety systems.

Q2:Can theFC-RUSIO-3224support analog and digital signals simultaneously?
A2:Yes, each channel can be configured individually for DI, DO, AI, or AO operation.

Q3:Does the module support redundant configurations?
A3:Yes, two modules can be combined to create a redundant safety IO configuration.

Q4:What communication protocol does the module use?
A4:It uses dedicated Ethernet-based Safety Manager communication links.

Q5:Is theFC-RUSIO-3224suitable for hazardous industrial environments?
A5:Yes, it is designed for critical industrial safety applications and carries multiple international certifications.

Spares

Number	Describe
RUSIO-3224	Universal Safe IO device (32 channels, 24 V DC)
RUSLS-3224	Universal Safe Logic Solver (32 channels, 24 V DC)
SDO-0824	Safe digital output module (24 V DC, 0.55 A, 8 channels)
SAO-0220m	Safe analog output module (0(4)-20 mA, 2 channels)
DO-1224	Non-safe digital output module (24 V DC, 0.55 A, 12 channels)
RO-1024	Non-safe relay output module (contacts, 10 channels)
DO-1624	Non-safe digital output module (24 V DC, 0.1 A, 16 channels)
SDO-04110	Safe digital output module (110 V DC, 0.32 A, 4 channels)
SDO-0448	Safe digital output module (48 V DC, 0.75 A, 4 channels)
SDO-0424	Safe digital output module (24 V DC, 2 A, 4 channels)
SDOL-0424	Safe loop-monitored digital output module (24 V DC, 1 A, 4 channels)
SDOL-0448	Safe loop-monitored digital output module (48 V DC, 500 mA, 4 channels)
